Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01304-0010N

CASE;TIMING GEAR

desc: CARTER

1шт.

2

06.22022-1013

PIN;DOWEL

desc: GOUJON

2шт.

3

65.01903C0021

GASKET

desc: JOINT

1шт.

4

06.01913-3113

BOLT ASS'Y M8X20

desc: BOULON A 6 PANS

5шт.

5

06.06225-0704

BOLT;STUD M8X20

desc: BOULON A 6 PANS

1шт.

6

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

7

06.11063-8214

NUT;HEX. M8

desc: ECROU 6 PANS

1шт.

8

06.01943-3317

BOLT ASS'Y M12X1.5X30

desc: BOULON A 6 PANS

4шт.

9

65.90201-0048

BOLT;STUD

desc: BOULON A 6 PANS

1шт.

10

06.06225-0809

BOLT;STUD M10X35

desc: BOULON A 6 PANS

6шт.

11

65.01903B0113

GASKET

desc: JOINT

1шт.

12

06.22022-0907

PIN;DOWEL

desc: GOUJON

2шт.

13

65.01305-5028C

COVER;TIMING GEAR CASE

desc: COUVERCLE

1шт.

14

06.01923-2914

BOLT ASS'Y M6X22

desc: BOULON A 6 PANS

13шт.

15

65.01510-0157

SEAL;OIL

desc: JOINT

1шт.

16

65.01903B0029

GASKET

desc: JOINT

1шт.

17

65.01307-5009

COVER;TIMING GEAR CASE

SERIAL: 051005

1шт.

17

65.01307-5002

COVER;TIMING GEAR CASE

SERIAL: 051006

1шт.

18

06.01923-2918

BOLT ASS'Y M6X35

desc: BOULON A 6 PANS

9шт.

19

65.90201-0146

BOLT;STUD M6X16

desc: BOULON A 6 PANS

2шт.

20

06.15010-2309

WASHER;PLAIN

desc: RONDELLE PLATE

2шт.

21

06.16731-2105

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

22

06.11063-8212

NUT;HEX

desc: ECROU 6 PANS

2шт.

23

65.27901-0005B

GASKET

SERIAL: 051005

1шт.

24

65.91605-0009

COVER;END

SERIAL: 051005

1шт.

25

06.01913-2911

BOLT ASS'Y M6X16

SERIAL: 051005

4шт.

26

65.54302-0021

PLATE;AIR COMPRESSOR

SERIAL: 050113

1шт.

26

65.54302-0021A

PLATE;AIR COMPRESSOR

SERIAL: 050114

1шт.

27

65.95840-0033

BRACKET;IDLE PULLEY

desc: SUPPORT

1шт.

28

06.01913-3215

BOLT ASS'Y M10X25

desc: BOULON A 6 PANS

3шт.

29

65.54903A0013

GASKET

desc: JOINT

1шт.

30

06.02090-0511

BOLT;SOCKET HEAD M10X22

desc: BOULON A 6 PANS CREUX

2шт.

31

06.02090-0513

BOLT;SOCKET HEAD

desc: BOULON A 6 PANS CREUX

2шт.

32

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

4шт.

33

65.05701-5266

OIL PIPE ASS'Y

SERIAL: 011008

1шт.

33

65.05701-5456

OIL PIPE ASS'Y

SERIAL: 011009

1шт.

34

65.98150-0056

SCREW;HOLLOW

desc: VIS

1шт.

35

06.56180-0712

RING;SEAL

desc: BAGUE

2шт.

36

65.54306-0003

BRACKET;ANGLE

desc: SUPPORT

1шт.

37

65.91701-0273

RING;SPACER

desc: BAGUE

1шт.

38

06.01013-9517

BOLT;HEX. M16X60

desc: BOULON A 6 PANS

1шт.

39

06.01913-3215

BOLT ASS'Y M10X25

desc: BOULON A 6 PANS

2шт.
