INTERMEDIATE GEAR

Запчасти Doosan Daewoo INTERMEDIATE GEAR ENGINE PARTS

4
2
3
1
22
2
30
3
33
5
40
6
43
37
42
32
34
41
35
36
31
45
44
24
38
23
39
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

65.05200-6034

IDLE GEAR MOUNTING ASS'Y

SC: D

1шт.

2

06.31420-0314

BEARING;BALL 6006 C

desc: PALIER

2шт.

3

06.29020-0132

RING;SNAP

desc: BAGUE

2шт.

4

65.05205-0018

PIN;IDLE GEAR

desc: GOUJON

1шт.

5

06.29010-0125

RING;SNAP

desc: BAGUE

1шт.

6

65.90030-0009

BOLT;SOCKET HEAD M10X60

desc: BOULON A 6 PANS CREUX

1шт.

22

06.22022-0907

PIN;DOWEL

desc: GOUJON

2шт.

23

06.01013-9215

BOLT;HEX. M10X1.5X50

desc: BOULON A 6 PANS

2шт.

24

65.90801-0038

WASHER;LOCK

SERIAL: 030316

2шт.

24

65.90801-0018

WASHER;LOCK

SERIAL: 030317

2шт.

30

65.05100-6022

OIL PUMP ASS'Y

desc: POMPE

1шт.

31

65.05102-0014

HOUSING;OIL PUMP

desc: . CARTER

1шт.

32

65.05103-5015

COVER ASS'Y

desc: . COUVERCLE

1шт.

33

65.05103-5012

OIL PUMP COVER ASS'Y(RR)

desc: . ENSEMBLE POMPE A HUILE(8-22)

1шт.

34

65.05410-0025

VALVE PLUNGER

desc: . PLAUE

1шт.

35

65.97601-0110

COMP. SPRING

desc: . COMPRESSEUR

1шт.

36

65.90310-0104

SCREW;PLUG

desc: . VIS

1шт.

37

65.05104-5004

GEAR ASS'Y;OIL PUMP

desc: . PIGNON

1шт.

38

65.05104-5003

GEAR ASS'Y;OIL PUMP

desc: . PIGNON

1шт.

39

06.01013-9118

BOLT: HEX M8X65

desc: . BOUND A 6PANS

4шт.

40

65.90510-0012

CLEVELOC NUT

desc: . ATTACHE

4шт.

41

65.05201-0037

OIL PUMP DRIVE GEAR

desc: . ENSEMBLE POMPE A HUILE(8-22)

1шт.

42

06.29141-0207

KEY. WOODRUFF 3X13X5

desc: . CLE

1шт.

43

06.22022-0909

PIN

desc: . GOUJON

4шт.

44

06.11053-9217

NUT. HEX M14X1.5

desc: . ECROU

1шт.

45

06.16050-0311

WASHER; LOCK

desc: . RONDELLE ELASTIQUE

1шт.
