Запчасти Doosan Daewoo SEALED TRACK SHOE-OPT OPTION PARTS

1

273-00048

SEALED TRACK SHOE;600G

desc: ENSEMBLE MAILLON DE CHAINES

2шт.

1

273-00050

SEALED TRACK SHOE;700G

desc: ENSEMBLE MAILLON DE CHAINES

2шт.

1

273-00051

SEALED TRACK SHOE;800G

desc: ENSEMBLE MAILLON DE CHAINES

2шт.

1

273-00052

SEALED TRACK SHOE;850G

desc: ENSEMBLE MAILLON DE CHAINES

2шт.

1-1

272-00026

SEALED TRACK LINK ASS'Y

desc: . TRAIN A MAILLON

1шт.

1-1A

2272-9008

LINK(R.H)

desc: .. PIECE DE JONCTION

50шт.

1-1B

2272-9009

LINK(L.H)

desc: .. PIECE DE JONCTION

50шт.

1-1C

2123-1320

PIN

desc: .. BROCHE

50шт.

1-1D

110-00180

BUSHING

desc: .. DOUILLE

50шт.

1-1E

2123-1628A

PIN;MASTER

desc: .. BROCHE PRINCIPALE

1шт.

1-1F

2110-1105

BUSHING;MASTER

desc: .. DOUILLE PRINCIPALE

1шт.

1-1G

2114-1552

SPACER

desc: .. ENTERTOISE

2шт.

1-1H

2123-1629

PIN

desc: .. BROCHE

1шт.

1-1J

2272-1056

LINK;MASTER(R.H)

desc: .. PIECE DE JONCTION

1шт.

1-1K

2272-1057

LINK;MASTER(L.H)

desc: .. PIECE DE JONCTION

1шт.

1-1L

180-00409

SEAL;DUST

desc: .. JOINT

100шт.

1-2

2273-9012

SHOE;600G

desc: . SABOT

51шт.

1-2

2273-9015A

SHOE;700G

desc: . SABOT

51шт.

1-2

2273-9016A

SHOE;800G

desc: . SABOT

51шт.

1-2

2273-9017A

SHOE;850G

desc: . SABOT

51шт.

1-3

2120-1212A

BOLT

desc: . BOULON A 6 PANS

204шт.

1-4

2121-1203

NUT

desc: . ECROU

204шт.

2

2625-1220D1

STEP;700G

desc: MARCHER

4шт.

2

2625-1220D3

STEP;800G

desc: MARCHER

4шт.

2

2625-1220D3

STEP;850G

desc: MARCHER

4шт.

4

S0558253

BOLT

desc: BOULON A 6 PANS

16шт.

5

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

16шт.
