Запчасти Doosan Daewoo FUEL INJECTION PUMP DRIVE ENGINE PARTS

1

65.11301-7008A

INJECTION PUMP DRIVE ASS'Y

SERIAL: 011213

1шт.

1

65.11301-7008B

INJECTION PUMP DRIVE ASS'Y

SERIAL: 030526

1шт.

1

65.11301-7008C

INJECTION PUMP DRIVE ASS'Y

SERIAL: 030527

1шт.

2

65.11309-0005A

HOUSING;INJECTION PUMP DRIVE

SERIAL: 011213

1шт.

2

65.11309-0005B

HOUSING;INJECTION PUMP DRIVE

SERIAL: 030526

1шт.

2

65.11309-0005C

HOUSING;INJECTION PUMP DRIVE

SERIAL: 030527

1шт.

3

06.32092-0307

BEARING;TAPER ROLLER

desc: . PALIER

2шт.

4

65.01510-0039

SEAL;OIL

desc: . JOINT

1шт.

5

65.11308-0001

SHIM 0.50

SC: R

1шт.

5

65.11308-0002

SHIM 0.20

SC: R

1шт.

5

65.11308-0003

SHIM 0.15

SC: R

1шт.

5

65.11308-0004

SHIM 0.10

SC: R

1шт.

9

65.11312-0006

COVER

desc: . COUVERCLE

1шт.

10

06.01913-3114

BOLT ASS'Y M8X22

desc: . BOULON A 6 PANS

3шт.

11

65.11302-0010A

SHAFT;INJECTION PUMP DRIVE

desc: . ARBRE

1шт.

12

06.29141-0215

KEY;WOODRUFF

desc: . CLAVETTE

1шт.

13

65.11301-0009

GEAR;INJECTION PUMP DRIVE

desc: . PIGNON

1шт.

14

06.11250-4329

NUT;HEX M24X1.5

desc: . ECROU

1шт.

15

06.16050-0316

WASHER;LOCK

desc: . RONDELLE

1шт.

16

65.98112-0027

FLANGE

desc: . BRIDE

1шт.

17

06.01913-2910

BOLT;HEX. M6X12

desc: . BOULON A 6 PANS

2шт.

18

65.11902-0018A

GASKET;MOUNTING FLANGE

desc: JOINT

1шт.

19

06.22220-1110

PIN;SPRING

desc: GOUJON

1шт.

20

06.15010-2312

WASHER;PLAIN

desc: RONDELLE PLATE

7шт.

21

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

7шт.

22

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS

7шт.
