Запчасти Doosan Daewoo COOLING SYSTEM ENGINE PARTS

1

65.01705-0002

COVER;WATER CHAMBER

SERIAL: 040909

1шт.

1

65.01705-0002B

COVER;WATER CHAMBER

SERIAL: 040910

1шт.

2

65.01907A0002

GASKET;WATER CHAMBER COVER

desc: JOINT

1шт.

3

06.15010-2311

WASHER

desc: RONDELLE

12шт.

4

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

12шт.

5

06.01923-3115

BOLT ASS'Y M8X25

desc: BOULON A 6 PANS

14шт.

6

65.90201-0149

BOLT;STUD M8X25

SERIAL: 030714

11шт.

6

65.90201-0149

BOLT;STUD M8X25

SERIAL: 030715

10шт.

7

65.90201-0037

BOLT;SPACER

SERIAL: 030714

1шт.

7

65.90201-0075

BOLT;SPACER

SERIAL: 030715

2шт.

8

06.11063-8214

NUT;HEX. M8

desc: ECROU 6 PANS

11шт.

9

65.06301-0134B

PIPE;COOLING WATER

desc: CONDUITE

1шт.

10

65.06903A0011

GASKET;COOLING WATER PIPE

desc: JOINT

3шт.

11

06.01923-3122

BOLT ASS'Y M8X55

desc: BOULON A 6 PANS

3шт.

12

06.01923-3124

BOLT ASS'Y M8X65

desc: BOULON A 6 PANS

3шт.

13

65.27435-6003

SWITCH;WATER TEMPERATURE

SERIAL: 020123

1шт.

13

65.90320-0019

PLUG;SCREW

SERIAL: 020124

1шт.

14

65.90310-0149A

SCREW;PLUG M26X1.5

desc: VIS

1шт.

15

06.56190-0728

RING;SEAL

desc: BAGUE

1шт.

16

65.96301-0257

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

17

06.67020-0110

CLAMP;HOSE

SERIAL: 030113

2шт.

17

06.67020-0109

CLAMP;HOSE

SERIAL: 030114

2шт.

18

65.06301-0083

PIPE;COOLING WATER

desc: CONDUITE

1шт.

19

04.27405-1908A

HOSE;RUBBER M50X62X80

desc: TUYAU FLEXIBLE

2шт.

20

06.67020-0109

CLAMP;HOSE

desc: COLLIER

4шт.

21

65.96301-0258

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

22

06.67020-0106

CLAMP;HOSE

desc: COLLIER

2шт.

23

65.06401-6044

THERMOSTAT ASS'Y

desc: THERMOSTAT

1шт.
