Запчасти Doosan Daewoo ELECTRIC WIRING(2)-ENGINE BODY PARTS

-

500-00116

ELECTRIC WIRING(2)

SC: D

-2шт.

3

530-00211

HARNESS;ENGINE

desc: FAISCEAU

1шт.

3A

2548-1027

DIODE ASS'Y 3A

desc: . DIODE

2шт.

17

2553-1275D5

CABLE;ENGINE-EARTH

desc: CABLE

1шт.

18

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

1шт.

19

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

20

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

21

2195-3500

BRACKET;HOUSING

desc: SUPPORT

1шт.

22

S3450953

SCREW M6X1.0X12

desc: VIS

1шт.

23

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

1шт.

24

2197-1660

BRACKET;HOUSING W15

desc: SUPPORT

1шт.

25

2197-1661

BRACKET;HOUSING W9

desc: SUPPORT

2шт.

26

2120-2187

BOLT;STUD M8X1.25X12/M8

desc: BOULON A 6 PANS

5шт.

27

120-00246

BOLT;STUD M10X1.5

desc: BOULON A 6 PANS

2шт.

28

2121-1305

NUT M8X1.25

desc: ECROU

7шт.

29

124-00208D2

CLIP D14/M8

desc: ATTACHE

6шт.

31

124-00208D4

CLIP D26/M8

desc: ATTACHE

2шт.

32

124-00208D5

CLIP D32/M8

desc: ATTACHE

3шт.

34

120-00276

BOLT M8X1.25X12

desc: BOULON A 6 PANS

8шт.

35

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

39

2124-1509D1

CLIP D12/M8

desc: ATTACHE

3шт.
