Запчасти Doosan Daewoo TRAVEL REDUCTION DEVICE HYDRAULIC PARTS

-

2401-9269

TRAVEL DEVICE

desc: MOTEUR DE TRANSLATION

2шт.

1

132970

GEAR;RING

desc: PIGNON

1шт.

2

132971

HOUSING(LH)

desc: CARTER

1шт.

4

132972

SIDE COVER

desc: COUVERCLE

1шт.

5

132973

CARRIER NO.1

desc: CARRIER

1шт.

6

132976

CARRIER NO.2

desc: CARRIER

1шт.

9

132983

SUN GEAR NO.1

desc: PIGNON

1шт.

10

132984

SUN GEAR NO.2

desc: PIGNON

1шт.

11

132985

SUN GEAR NO.3

desc: PIGNON

1шт.

12

132974

PLANETARY GEAR NO.1

desc: PIGNON

2шт.

13

132977

PLANETARY GEAR NO.2

desc: PIGNON

3шт.

14

132980

PLANETARY GEAR NO.3

desc: PIGNON

4шт.

16

132979

PIN NO.2

desc: BROUCHE

3шт.

17

132981

PIN NO.3

desc: BROUCHE

4шт.

18

132975

SIDE PLATE E

desc: PLAQUE

2шт.

19

132978

SIDE PLATE A

desc: PLAQUE

6шт.

20

132960

SIDE PLATE F

desc: PLAQUE

8шт.

21

230581

NEEDLE CAGE

desc: PALIER

2шт.

22

230584

NEEDLE CAGE

desc: PALIER

3шт.

23

230585

NEEDLE CAGE

desc: PALIER

4шт.

24

230582

INNER RING

desc: BAGUE

2шт.

25

132982

FLOATING BUSH

desc: DOUILLE

4шт.

26

132986

THRUST RING 60

desc: BAGUE

1шт.

27

132987

THRUST RING 90

desc: BAGUE

1шт.

29

230587

BOLT;SOCKET M16X100

desc: BOULON

28шт.

30

230588

BOLT;SOCKET M8X20

desc: BOULON

12шт.

32

230589

PLUG

desc: BOUCHONE

3шт.

33

230590

ANGULAR BEARING

desc: PALIER

2шт.

34

132988

FLOATING SEAL

desc: ETANCHEITE

1шт.

35

132989

SHIM

desc: CALE

1шт.

36

101226

SPRING PIN

desc: RESSORT

3шт.

37

230586

RING;SNAP

desc: BAGUE

4шт.

44

230583

RING;SNAP

desc: BAGUE

2шт.

45

230591

CLIP

desc: ATTACH

1шт.

46

230592

CLIP

desc: ATTACH

1шт.

47

230596

RING;SNAP

desc: BAGUE

1шт.

48

230593

RING;SNAP

desc: BAGUE

1шт.

81

230594-CPP323

O-RING

desc: PLAQUE

1шт.

82

230595

O-RING

desc: PLAQUE

1шт.
