Запчасти Doosan Daewoo PEDAL VALVE HYDRAULIC PARTS

-

2420-9617A

PEDAL VALVE

SERIAL: 1025-1044

1шт.

1

J98D3001

CASING SUB ASS'Y

desc: ENSEMBLE DE CARTER

2шт.

2

J24D2004

COVER

desc: COUVERCLE

2шт.

3

DU1010

BUSH

desc: DOUILLE

4шт.

4

J24D2005

CAM

desc: CAME

2шт.

5

J24D2006

BELLOWS

desc: SOUFFLET

2шт.

6

J24D2007

SPOOL

desc: BOBINE

4шт.

7

S090601

SHIM

SC: R

-2шт.

8

J24D2008

SPRING;SEAT

desc: RESSORT

4шт.

9

J98D3002

SPRING

desc: RESSORT

4шт.

10

J24D2010

SPRING;SEAT

desc: RESSORT

4шт.

11

J24D2011

STOPPER

desc: ARRET

4шт.

12

J24D2012

PLUG

desc: BOUCHON

4шт.

13

P0020

O-RING 1BP-20

desc: JOINT TORIQUE

4шт.

14

DSP10

SEAL;DUST

desc: PARE-POUSSIERES

4шт.

15

RSY10

SEAL;ROD

desc: TIGE D'ETANCHEITE

4шт.

16

J98D3003

SPRING

desc: RESORT

4шт.

17

J98D3004

ROD;PUSH

desc: TIGE

4шт.

18

WBM0830

BOLT;WRENCH

desc: BOULON

4шт.

19

J24D2015

SCREW;SET

desc: VIS

4шт.

20

HNM10

NUT

desc: ECROU

4шт.

21

J24D2016

SHAFT;CAM

desc: ARBRE A CAMES

2шт.

22

SBM0812

SCREW;SET

desc: VIS

2шт.

23

WPT18

PLUG PT1/8

desc: BOUCHON

2шт.

24

WPT38

PLUG PT3/8

desc: BOUCHON

2шт.

25

J98D3005

SPACER

desc: BAGUE

1шт.

26

P0012

O-RING 1BP-12

desc: JOINT TORIQUE

4шт.

27

WBM0845

BOLT;WRENCH M8X38

desc: BOULON

4шт.
