Запчасти Doosan Daewoo PISTON ENGINE PARTS
2
3
4
6
1
5
6
11
8
7
12
12
10
9
1
65.02501-0203
PISTON
SERIAL: 970012
6шт.
1
65.02501-0203A
PISTON
SERIAL: 970013
6шт.
1
65.02501-0785
PISTON
SERIAL: 981208
6шт.
2
65.02503-0054
RING;TOP 111X3.5
desc: SEGMENT SUPERIEUR
6шт.
3
65.02503-0091
RING;SECOND 111X3.5
desc: SEGMENT INFERIEUR
6шт.
3
65.02503-0120
RING;SECOND 111X3.5
SERIAL: 970013
6шт.
4
65.02503-0115
RING;OIL 111X4
desc: SEGMENT RACLEUR
6шт.
5
65.02502-0010
PIN;PISTON 42X2.X95
desc: AXE DE PISTON
6шт.
6
06.29020-0126
RING;SNAP 42X1.75
desc: CIRCLIP
12шт.
7
65.02401-6101D
CONNECTING ROD ASS'Y
SERIAL: 000901
6шт.
7
65.02401-6101E
CONNECTING ROD ASS'Y
SERIAL: 000902
6шт.
8
65.02401-0030
ROD;CONNECTING
SC: D
6шт.
9
65.90020-0009C
BOLT;CONNECTING ROD
SERIAL: 000901
2шт.
9
65.90020-0009D
BOLT;CONNECTING ROD
SERIAL: 000902
2шт.
10
65.91301-0010
PIN;DOWEL
SC: D
2шт.
11
65.02405-0015C
BUSH;SMALL END
SC: D
1шт.
12
65.02410-0010
METAL;CONN ROD STD
desc: COUSSINET TETE DE BIELLE STD
6шт.
12
65.02410-0011
METAL;CONN ROD 0.25mm
SC: US
6шт.
12
65.02410-0012
METAL;CONN ROD 0.50mm
SC: US
6шт.
12
65.02410-0013
METAL;CONN ROD 0.75mm
SC: US
6шт.
