Запчасти Doosan Daewoo INTAKE & EXHAUST MANIFOLD ENGINE PARTS

1

65.08201-6001

INTAKE MANIFOLD

SERIAL: 990210

1шт.

1

65.08201-5055

INTAKE MANIFOLD

SERIAL: 990211

1шт.

1-1

65.08201-5050

HOUSING;INTAKE

SERIAL: 990210

1шт.

1-2

65.90310-0143

SCREW;PLUG

SERIAL: 990210

3шт.

1-3

06.56180-0716

RING;SEAL

SERIAL: 990210

3шт.

2

65.08902-0024

GASKET;INTAKE MANIFOLD

SERIAL: 970213

1шт.

2

65.08902A0024

GASKET;INTAKE MANIFOLD

SERIAL: 970214

1шт.

3

06.15030-0514

WASHER

desc: RONDELLE 1

2шт.

4

06.16731-2108

WASHER;SPRING

desc: RONDELLE

2шт.

5

06.06225-0809

BOLT;STUD M10X35

desc: BOULON A 6 PANS

2шт.

6

06.11063-8215

NUT;HEX

desc: ECROU 6 PANS

2шт.

10

65.08100-6056

EXHAUST MANIFOLD ASS'Y

desc: COLLECTEUR D'ECHAOOEMENT

1шт.

11

65.08101-0193

MANIFOLD;EXHAUST(LH)

desc: . COLLECTEUR ECHAPPEMENT

1шт.

12

65.08101-0195

MANIFOLD;EXHAUST(MIDDLE)

desc: . COLLECTEUR ECHAPPEMENT

1шт.

13

65.08101-0194

MANIFOLD;EXHAUST(RH)

desc: . COLLECTEUR ECHAPPEMENT

1шт.

14

65.96501-0007

RING;SEAL

desc: . BAGUE D'ETANCHEITE

4шт.

15

65.08901A0013

GASKET;EXHAUST MANIFOLD

desc: JOINT DE COLLECTEUR D'ECHAPPEMENT

6шт.

16

06.06226-0808

BOLT;STUD M10X30

desc: BOULON A 6 PANS

6шт.

17

65.08120-5018B

SCREEN;HEAT

desc: ECRAN THERMIQUE

1шт.

18

06.15010-2312

WASHER

desc: RONDELLE

6шт.

19

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS

6шт.

20

65.90201-0049

BOLT;STUD

desc: GOUJON

6шт.

21

06.15010-2312

WASHER

desc: RONDELLE

6шт.

22

06.11063-9216

NUT;HEX. M12X1.5

desc: ECROU

6шт.

23

65.08120-0017

SCREEN;HEAT

desc: ECRAN THERMIQUE

1шт.

26

06.01933-3218

BOLT ASS'Y

desc: BOULON A 6 PANS

10шт.

27

65.09501-7002

INTER COOLER ASS'Y

desc: REFREGERATOR

1шт.

28

06.01923-3113

BOLT;HEX. M8X20

desc: BOULON A 6 PANS

17шт.

29

06.01923-3115

BOLT;HEX. M8X25

desc: BOULON A 6 PANS

1шт.

30

65.09905-0001

GASKET

SERIAL: 970520

1шт.

30

65.09905-0003

GASKET

SERIAL: 970521

1шт.
