Запчасти Doosan Daewoo ELECTRIC WIRING(2)-ENGINE BODY PARTS

-

2500-1232

ELECTRIC PARTS(3)

SC: D

-2шт.

3

2530-1631A

HARNESS;ENGINE

SERIAL: 1001-1023

1шт.

3

2530-1631B

HARNESS;ENGINE

SERIAL: 1024-1060

1шт.

3

2530-1631C

HARNESS;ENGINE

SERIAL: 1061

1шт.

15

S0511653

BOLT M10X1.5X16

desc: BOULON A 6 PANS

1шт.

16

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

1шт.

17

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

18

S5010613

WASHER;PLAIN

desc: RONDELLE

2шт.

19

2195-3500

BRACKET;HOUSING

desc: SUPPORT

1шт.

20

S3450953

SCREW M6X1.0X12

desc: VIS

1шт.

22

2197-1660

BRACKET;HOUSING

desc: SUPPORT

1шт.

23

2197-1661

BRACKET;HOUSING

desc: SUPPORT

3шт.

24

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

3шт.

25

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

3шт.

26

2120-2159

BOLT;STUD

desc: BOULON A 6 PANS

3шт.

27

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

3шт.

30

2124-1509D3

CLIP D24/M8

desc: ATTACHE

6шт.

31

2124-1509D4

CLIP D30/M8

desc: ATTACHE

2шт.

33

2121-1305

NUT M8X1.25

desc: ECROU

8шт.

37

2553-1275D5

CABLE;ENGINE EARTH 60B-300L

desc: CABLE

1шт.

38

2124-1353D13

CLIP D25/M10

desc: ATTACHE

1шт.
