Запчасти Doosan Daewoo AIRCONDITIONER(1) BODY PARTS

-

2920-1093

COOLER & HEATER ASS'Y

SC: D

-2шт.

1

2543-9031

PANEL;AIRCON CONTROL

SERIAL: 1001-1023

1шт.

1

2543-9031A

PANEL;AIRCON CONTROL

SERIAL: 1024

1шт.

2

S3450583

SCREW M4X0.7X12

desc: VIS

4шт.

3

S5000113

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

4

2208-6013B

COMPRESSOR 10PA-15C

desc: COMPRESSEUR

1шт.

5

S0557353

BOLT M8X1.25X100

SERIAL: 1001-1029

2шт.

5

S0557763

BOLT M8X1.25X120

SERIAL: 1030

2шт.

6

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

7

S5010513

WASHER;PLAIN

SERIAL: 1001-1029

2шт.

7

S5010513

WASHER;PLAIN

SERIAL: 1030

4шт.

8

S4012533

NUT M8X1.25

desc: ECROU

2шт.

9

2107-6004B

PULLEY;IDLE

desc: ENSEMBLE POULIE FOU

1шт.

10

2106-1019D2

V-BELT 1480L

desc: COURROIE

1шт.

11

2185-1700

HOSE;DISCHARGE

desc: TUYAU FLEXIBLE

1шт.

11A

2180-6088

O-RING;DISCHARGE-COMP

desc: . JOINT TORIQUE

1шт.

11B

2180-6089

O-RING;DISCHARGE-CONDENSER

desc: . JOINT TORIQUE

1шт.

11C

1.161-00018

CAP;CHECK PORT(H)

desc: . CHAPEAU

1шт.

12

2185-1747

HOSE;SUCTION

desc: TUYAU FLEXIBLE

1шт.

12A

2180-6086

O-RING;SUCTION-COMP

desc: . JOINT TORIQUE

1шт.

12B

2180-6087

O-RING;SUCTION-EVATOR

desc: . JOINT TORIQUE

1шт.

12C

1.161-00019

CAP;CHECK PORT(L)

desc: . CHAPEAU

1шт.

13

2520-6004

CONDENSER ASS'Y

desc: ENSEMBLE COMPRESSEUR

1шт.

13A

2520-6005

CONDENSER CORE ASS'Y

desc: . ENSEMBLE COMPRESSEUR

1шт.

13B

2538-6018

MOTOR;CONDENSER 24V

desc: . MOTEUR

1шт.

13C

2520-6006

CONDENSER NET

desc: . ENSEMBLE COMPRESSEUR

1шт.

14

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

6шт.

15

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

16

S5010613

WASHER;PLAIN

desc: RONDELLE

6шт.

17

2185-1697D1

HOSE;LIQUID(1)

desc: TUYAU FLEXIBLE

1шт.

17A

2180-6090

O-RING;LIQUID(1)

desc: . JOINT TORIQUE

2шт.

18

2185-1698D3

HOSE;LIQUID(2)

desc: TUYAU FLEXIBLE

1шт.

18A

2180-6090

O-RING;LIQUID(2)

desc: . JOINT TORIQUE

2шт.

19

2204-6039

RECEIVER DRIER

SERIAL: 1001-1020

1шт.

19

2204-6039A

RECEIVER DRIER

SERIAL: 1021

1шт.

20

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

4шт.

21

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

29

2124-1059D2

CLIP D36/M8

desc: ATTACHE

2шт.

30

2124-1509D3

CLIP D42/M8

desc: ATTACHE

2шт.

32

2124-1509D6

CLIP D42/M8

desc: ATTACHE

2шт.

33

2121-1305

NUT M8X1.25

desc: ECROU

6шт.

35

2124-1509D2

CLIP D18/M8

desc: ATTACHE

1шт.
