Запчасти Doosan Daewoo ARM PIPING(3.1M)-ROTATION & TILTING OPTION PARTS

-

400-00840

PIPING;3.1m ARM ROTATION&TILTING

SERIAL: 1551

-2шт.

1

701-00406

ARM;ROTATION&TILTING

desc: BALANCIER

1шт.

2

DS2013358

HOSE-1400L

desc: TUYAU FLEXIBLE

2шт.

3

140-01090

PIPE;ARM

desc: TUYAU

2шт.

4

140-01115A

PIPE;TILTING

desc: TUYAU

2шт.

5

193-00625A

PIPE;ROTATING

desc: TUYAU

2шт.

6

420-00277

VALVE;SWITCH

desc: VANNE

2шт.

7

2181-1702D2

ELBOW PFO1/2-PF1/2

desc: COUDE

2шт.

8

111-00031D1

ADAPTER;UNION PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

6шт.

9

2181-1126D6

ADAPTER PFO1/2-PF1/2

desc: RACCORD ADAPTATEUR

4шт.

10

2181-2820D3

PLUG

desc: BOUCHON

4шт.

11

S8000181

O-RING

desc: JOINT TORIQUE

2шт.

12

124-00204A

CLAMP

desc: COLLIER

10шт.

13

S2212066

BOLT;SOCKET M10X1.5X25

desc: BOULON A 6 PANS CREUX

20шт.

14

161-00313

RUBBER

desc: CAOUTCHOUC

20шт.

15

S8030081

O-RING

desc: JOINT TORIQUE

2шт.

16

2181-4133D3

ADAPTER PF1/2-UNF13/16-16

desc: RACCORD

2шт.
