Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01903C0021

GASKET;TIMING GEAR CASE

desc: JOINT(CARTER DE DISTRIBUTION)

1шт.

2

65.01304-0010M

CASE;TIMING GEAR

SERIAL: 000730

1шт.

2

65.01304-0010N

CASE;TIMING GEAR

SERIAL: 000731

1шт.

5

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

1шт.

6

06.01913-3113

BOLT;HEX M8X20

desc: BOULON A 6 PANS

5шт.

7

06.06225-0704

BOLT;STUD M8X20

desc: BOULON A 6 PANS

1шт.

7A

06.11063-8214

NUT;HEX M8

desc: ECROU 6 PANS

1шт.

8

06.01943-3317

BOLT;HEX M12X1.5X30

desc: BOULON A 6 PANS

4шт.

9

65.90201-0048

BOLT;STUD

desc: GOUJON

1шт.

10

06.06225-0809

BOLT;STUD M10X35

desc: BOULON A 6 PANS

4шт.

10

06.06225-0810

BOLT;STUD

desc: GOUJON

2шт.

10

06.06225-0809

BOLT;STUD M10X35

desc: BOULON A 6 PANS

6шт.

12

65.01903B0113

GASKET;TIMING GEAR COVER

desc: JOINT

1шт.

13

65.01305-5028A

TIMING GEAR CASE COVER

SERIAL: 001215

1шт.

13

65.01305-5028C

TIMING GEAR CASE COVER

SERIAL: 001216

1шт.

16

06.01923-2914

BOLT;HEX M6X22

desc: BOULON A 6 PANS

13шт.

18

65.01903B0029

GASKET;TIMING GEAR COVER

desc: JOINT

1шт.

19

65.01307-5009

TIMING GEAR CASE COVER

SERIAL: 051005

1шт.

19

65.01307-5002

TIMING GEAR CASE COVER

SERIAL: 051006

1шт.

20

06.15010-2309

WASHER

desc: RONDELLE 6.4

2шт.

21

06.16731-2105

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

22

06.01923-2918

BOLT;HEX. M6X35

desc: BOULON A 6 PANS

9шт.

23

06.06225-0502

BOLT;STUD M6X16

desc: BOULON A 6 PANS

2шт.

24

06.11063-8212

NUT;HEX M6

desc: ECROU 6 PANS

2шт.

25

06.22022-0907

PIN;DOWEL M6X12

desc: GOUPILLE D'AJUSTAGE

2шт.

26

65.01510-0026

SEAL;CRANK SHAFT(FRONT)

SERIAL: 990916

1шт.

26

65.01510-0157

SEAL;CRANK SHAFT(FRONT)

SERIAL: 990917

1шт.

27

65.54903A0013

GASKET

desc: JOINT

1шт.

28

65.54302-5017

BRACKET;AIRCON

SERIAL: 990430

1шт.

28

65.54302-0006

BRACKET;AIRCON

SERIAL: 990501

1шт.

28

65.54302-0006A

BRACKET;AIRCON

SERIAL: 000222

1шт.

29

06.02090-0511

BOLT;SOCKET HEAD M10X22

SERIAL: 990430

4шт.

29

06.02090-0511

BOLT;SOCKET HEAD M10X22

SERIAL: 990501

2шт.

31

65.54306-0003

ANGLE;BRACKET

desc: SUPPORT

1шт.

32

06.01913-3215

BOLT;HEX M10X1.5X25

desc: BOULON A 6 PANS

2шт.

34

65.95840-0033

BRACKET;IDLE PULLEY

desc: SUPPORT DE POULIE FOU

1шт.

36

06.01913-3213

BOLT;HEX M10X1.5X20

desc: BOULON A 6 PANS

3шт.

38

65.11401-0040

MOUNTING FLANGE ASS'Y

desc: ENSEMBLE SUPPORT DE MONTAGE

1шт.

39

65.11902-0018A

GASKET

desc: JOINT

1шт.

40

06.22220-1110

PIN;SPRING

desc: GOUPILLE D'AJUSTAGE

1шт.

41

06.15010-2312

WASHER;PLAIN

desc: RONDELLE

7шт.

42

06.16731-2108

WASHER;SPRING

desc: RONDELLE

7шт.

43

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS

7шт.

44

65.90201-0059

BOLT;STUD M10X35

desc: GOUJON

4шт.

47

65.93410-0036

BEARING;BALL

desc: PALIER

1шт.

48

06.02090-0513

BOLT;SOCKET M10X28

SERIAL: 990501

2шт.

49

06.16731-2108

WASHER;SPRING

desc: RONDELLE

4шт.

50

65.27901-0005B

GASKET;END COVER

SERIAL: 051005

1шт.

51

65.91605-0009

COVER;END

SERIAL: 051005

1шт.

52

06.01913-2911

BOLT;HEX. M6X16

SERIAL: 051005

4шт.
