Запчасти Doosan Daewoo COOLING WATER PUMP ENGINE PARTS

28
15
14
13
12
8
11
2
29A
19
30
23
21
20
29
31
7
6
5
1

Артикул

Название

Примечание

Количество

1

65.06500-6138A

WATER PUMP ASS'Y

SERIAL: 011227

1шт.

1

65.06500-6138B

WATER PUMP ASS'Y

SERIAL: 030515

1шт.

1

65.06500-6138C

WATER PUMP ASS'Y

SERIAL: 030516

1шт.

2

65.98115-0011

UNION

desc: . UNION

1шт.

5

65.06506-0023

IMPELLAR

desc: . TURBINE

1шт.

6

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

7

65.93410-0027

BEARING;UNIT

SC: D

1шт.

8

06.29020-0132

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

11

65.06504-0030

HUB

SERIAL: 030515

1шт.

11

65.06504-0030A

HUB

SERIAL: 030516

1шт.

12

65.06501-0075A

HOUSING;WATER PUMP

SERIAL: 011227

1шт.

12

65.06501-0075B

HOUSING;WATER PUMP

SERIAL: 030515

1шт.

12

65.06501-0075C

HOUSING;WATER PUMP

SERIAL: 030516

1шт.

13

65.06901A0019

GASKET;WATER PUMP

desc: . JOINT DE POMPE A EAU(INTERIEUR)

1шт.

14

65.06512-0010

COVER;WATER PUMP

desc: . COUVERCLE DE POMPE A EAU

1шт.

15

06.04201-8907

BOLT;M6X14

desc: . BOULON A 6 PANS

3шт.

19

65.06606-0037

PULLEY;V-BELT

desc: POULIE

1шт.

20

65.06611-0092

FLANGE

SERIAL: 030515

1шт.

20

65.06611-0092A

FLANGE

SERIAL: 030516

1шт.

21

65.06601-5046

FAN;COOLING

desc: VENTILATEUR

1шт.

23

06.01913-3129

BOLT;HEX. M8X90

desc: BOULON A 6 PANS

6шт.

28

65.06901A0020

GASKET;WATER PUMP

desc: JOINT

1шт.

29

06.01913-3125

BOLT;HEX. M8X70

desc: BOULON A 6 PANS

1шт.

29A

06.01913-3126

BOLT;HEX. M8X75

desc: BOULON A 6 PANS

1шт.

30

06.01913-3121

BOLT;HEX. M8X50

desc: BOULON A 6 PANS

3шт.

31

06.01914-3225

BOLT;HEX. M10X70

desc: BOULON A 6 PANS

1шт.

Выбрано товаров: 26
