Запчасти Doosan Daewoo ARM PIPING-7M OPTION PARTS

-

2400-2120

ARM PIPING-7m

SC: D

-2шт.

1

2440-9233B

CYLINDER;BUCKET

desc: VERIN DE GODET

1шт.

2

2184-1201D19

HOSE

SERIAL: 00001-50130

2шт.

2

2184-1201D30

HOSE

SERIAL: 50131

2шт.

3

2184-1100D189

HOSE

desc: TUYAU FLEXIBLE

2шт.

4

2140-1661

PIPE

desc: TUYAU

2шт.

5

2181-2627D12

ADAPTER;ORFS

desc: RACCORD ADAPTATEUR

2шт.

6

S8030161

O-RING

desc: JOINT TORIQUE

2шт.

7

S8000231

O-RING

desc: JOINT TORIQUE

2шт.

8

2181-9078

FLANGE;SPLIT PF3/4-5000psi

desc: FLASQUE EN DEUX PARTIES

8шт.

9

2124-1586

CLAMP;PIPE

desc: ATTACHE DE TUYAU

6шт.

10

S0565661

BOLT

desc: BOULON A 6 PANS

6шт.

11

S5102901

WASHER;SPRING

desc: RONDELLE GROWERM12

6шт.

12

2161-2267A

RUBBER

desc: CAOUTCHOUC

12шт.

13

S2212361

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

24шт.

14

2180-1026D19

O-RING

desc: JOINT TORIQUE

6шт.
