Запчасти Doosan Daewoo PILOT PIPING(3) BODY PARTS

-

2400-1826A

PILOT PIPING

SERIAL: 1-50220

-2шт.

7

S5102603

WASHER;SPRING M10

desc: RONDELLE GROWERM10

6шт.

11

2426-9040A

VAVLE;SOLENOID

desc: VANNE

1шт.

12

S0558953

BOLT M10X1.5X70

desc: BOULON A 6 PANS

2шт.

16

2423-1470

BLOCK

desc: BLOC

2шт.

17

S0558653

BOLT M10X1.5X55

desc: BOULON A 6 PANS

4шт.

25

S8000141

O-RING P14

desc: JOINT TORIQUE

5шт.

26

S8000111

O-RING P11

desc: JOINT TORIQUE

10шт.

27

2181-1126D14

ADAPTER PFO1/4-PF1/4

desc: RACCORD ADAPTATEUR

4шт.

28

2181-1126D7

ADAPTER PFO3/8-PF3/8

desc: RACCORD

3шт.

32

2181-1702D4

ELBOW PFO1/4-PF1/4

desc: COUDE

5шт.

69

2184-1046D117

HOSE PF1/4-1700L

desc: TUYAU FLEXIBLE

1шт.

71

2184-1036D113

HOSE PF3/8-1730L

desc: TUYAU FLEXIBLE

1шт.

73

2184-1060D41

HOSE PF1/4-1250L

desc: TUYAU FLEXIBLE

1шт.

74

2184-1060D39

HOSE PF1/4-1000L

desc: TUYAU FLEXIBLE

1шт.

75

2184-1060D109

HOSE PF1/4-1540L

desc: TUYAU FLEXIBLE

1шт.

76

2184-1046D155

HOSE PF1/4-1500L

desc: TUYAU FLEXIBLE

1шт.

91

2184-1060D153

HOSE PF3/8-1230L

desc: TUYAU FLEXIBLE

1шт.

114

2184-1046D183

HOSE PF3/8-830L

desc: TUYAU FLEXIBLE

1шт.

124

2181-1702D56

ELBOW PFO1/4-PF1/4

desc: COUDE

1шт.

133

2181-1951D11

TEE PFO3/8-PF3/8-PF1/4

desc: TE

1шт.

134

2181-1702D55

ELBOW PFO3/8-PF3/8

desc: COUDE

1шт.

135

2184-1046D83

HOSE PF1/4-830L

desc: TUYAU FLEXIBLE

1шт.
