Запчасти Doosan Daewoo ALTERNATOR BODY PARTS

-

2502-9009

ALTERNATOR

SERIAL: 50131

1шт.

1

0-35100-0300

ROTOR ASS'Y

desc: ROTOR

-1шт.

1-1

1-33923-0790

COLLAR

desc: . BRIDE

-1шт.

1-2

0-35923-0160

COLLAR

desc: . BAGUE

-1шт.

1-3

0-09201-0980

BEARING;BALL

desc: . PALIER

-1шт.

2

0-35200-0440

STATOR ASS'Y

desc: STATOR

-1шт.

3

0-35300-0310

F.BRACKET ASS'Y

desc: SUPPORT

-1шт.

3-1

0-35926-0070

RETAINER

desc: . BAGUE DE SOUTIEN

-1шт.

3-2

0-35926-0090

RETAINER

desc: . BAGUE DE SOUTIEN

-1шт.

3-3

1-33926-0730

RETAINER

desc: . BAGUE

-1шт.

3-4

0-35951-0060

PACKING

desc: . JOINT

-1шт.

3-5

0-09201-1140

BEARING;BALL

desc: . PALIER

-1шт.

3-6

0-0275-06802

BOLT

desc: . BOULON A 6 PANS

-1шт.

4

0-35411-0870

PULLEY

desc: POULIE

-1шт.

4-1

0-35421-0170

FAN

desc: . VENTILATEUR

-1шт.

4-2

0-0280-16022

NUT

desc: . ECROU

-1шт.

4-3

1-0335-16002

WASHER;SPRING

desc: . RONDELLE GROWER

-1шт.

4-4

1-0330-06012

WASHER;PLAIN

desc: RONDELLE PLATE

-1шт.

5

0-35120-0230

COIL;FIELD

desc: COIL

-1шт.

7

0-35700-0890

R.BRACKET ASS'Y

desc: SUPPORT

-1шт.

7-1

0-35710-1090

BRACKET;REAR

desc: . SUPPORT

-1шт.

7-2

0-35730-0510

RECTIFIER ASS'Y

desc: . RECTIFIER

-1шт.

7-3

0-35780-0750

TERMINAL ASS'Y

desc: . RECTIFIER

-1шт.

7-4

0-09170-2501

CONDENSER

desc: . CONDENSEUR

-1шт.

7-5

0-35923-0130

COLLAR

desc: . BAGUE

-1шт.

7-6

0-35923-0200

COLLAR

desc: . BAGUE

-1шт.

7-7

0-35943-0140

BUSH;INSULATE

desc: . DOUILLE

-1шт.

7-8

0-35943-0150

BUSH;INSULATE

desc: . DOUILLE

-1шт.

7-9

0-35943-0160

BUSH;INSULATE

desc: . DOUILLE

-1шт.

7-10

0-35943-0170

BUSH;INSULATE

desc: . DOUILLE

-1шт.

7-11

1-33953-0150

BUSH;GUM

desc: . DOUILLE

-1шт.

7-12

0-35761-0250

COVER

desc: . COUVERCLE

-1шт.

7-13

0-0056-05302

SCREW

desc: . VIS

-1шт.

7-14

1-33931-0021

CLIP

desc: . ATTACHE

-1шт.

8

0-35719-0200

REGULATOR ASS'Y

desc: REGULATEUR

-1шт.
