Запчасти Doosan Daewoo AIR CLEANER ASSY BODY PARTS

-

2204-2020A

AIR CLEANER ASS'Y-TURBO

SC: D

-2шт.

1

2204-2012A

AIR CLEANER

desc: FILTRE A AIR

1шт.

2

2124-1552

BAND;AIR CLEANER

desc: COLLIER FILTRE A AIR

2шт.

3

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

16шт.

4

S5010613

WASHER;PLAIN

desc: RONDELLE

6шт.

5

2161-2190A

SPONGE

desc: EPONGE

1шт.

7

2185-1656

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

8

2185-1657

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

9

2185-1658

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

11

2193-1385A

PIPE;AIR

SERIAL: 00001-50160

1шт.

11

2193-1385B

PIPE;AIR

SERIAL: 50161

1шт.

12

2193-1386A

PIPE;AIR

desc: CONDUITE

1шт.

13

S8450066

CLAMP;HOSE

desc: COLLIER

1шт.

14

2621-3706B

COVER

SERIAL: 00001-50160

1шт.

14

2621-3706C

COVER

SERIAL: 50161

1шт.

15

2114-1058D10

WASHER;PLAIN

desc: RONDELLE PLATE

10шт.

16

S8450127

CLAMP;HOSE

desc: COLLIER

5шт.

17

2170-9005

INDICATOR;AIR CLEANER

desc: INDICATEUR

1шт.

18

2204-9032A

PRE-CLEANER

desc: PRE-CLEANER

1шт.

19

S5102603

WASHER;SPRING M10

desc: RONDELLE GROWER

2шт.

20

2181-2690

ADAPTER;FILTER

desc: ADAPTATEUR

1шт.
