Запчасти Doosan Daewoo TRAVEL PIPING TRACK PARTS

-

2400-1436

TRAVEL PIPING

SERIAL: 5001-5324

-2шт.

1

2183-3496A

PIPE

desc: CONDUITE

2шт.

2

2183-3497A

PIPE

desc: CONDUITE

2шт.

3

S2215361

BOLT;SOCKET M12X1.75X35

desc: BOULON A 6 PANS CRUEX

48шт.

4

2180-1026D19

O-RING SAE1"

desc: JOINT TORIQUE

12шт.

5

2181-9081

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

16шт.

6

2184-9063A

HOSE 1"-1850L

desc: TUYAU FLEXIBLE

4шт.

7

2184-1071D24

HOSE 1/2"-2850L

desc: TUYAU FLEXIBLE

2шт.

8

2184-1070D40

HOSE PF1/4-3150L

desc: TUYAU FLEXIBLE

2шт.

9

2124-1084D1

CLIP;BAND

desc: ATTACHE

10шт.

10

2181-1126D6

ADAPTER PF1/2(O)XPF1/2

desc: RACCORD ADAPTATEUR

3шт.

11

S8000181

O-RING P18

REP_PNO: 8202-014

3шт.

12

2181-1126D14

ADAPTER PF1/4(O)XPF1/4

desc: RACCORD ADAPTATEUR

3шт.

13

S8000111

O-RING P11

REP_PNO: 8202-009

3шт.

14

2181-4124

TEE

desc: TE

1шт.

15

2181-6058

TEE

desc: TE

1шт.

16

2160-1172

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

2шт.

17

2160-1171

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

2шт.

18

2124-1024D5

CLAMP;PIPE

desc: ATTACHE DE TUBE

2шт.

19

S0560753

BOLT M12X1.75X50

desc: BOULON A 6 PANS

2шт.

21

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M12

2шт.

22

S5110701

WASHER;SPRING M12

REP_PNO: 8131-009

16шт.
