Запчасти Doosan Daewoo PILOT PIPING FOR BREAKER OPTION PARTS

-

2400-7066

PILOT PIPING FOR BREAKER

SERIAL: 6090

-2шт.

32

2181-1702D10

ELBOW PF3/8(O)XPF1/4

desc: COUDE

1шт.

33

S8000141

O-RING P14

REP_PNO: 8202-011

2шт.

34

2181-1126D36

ADAPTER PF3/8(O)XPF1/4

desc: RACCORD ADAPTATEUR

1шт.

35

2181-1951D1

TEE PF1/4(O)XPF1/4XPF1/4

desc: TE

2шт.

36

S8000111

O-RING P11

REP_PNO: 8202-009

7шт.

37

2420-9227A

VALVE;PACKAGE

desc: VANNE

1шт.

38

S0558953

BOLT M10X1.5X70

desc: BOULON A 6 PANS

3шт.

39

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

3шт.

40

2181-1126D14

ADAPTER PF1/4(O)XPF1/4

desc: RACCORD ADAPTATEUR

4шт.

41

2181-1702D4

ELBOW PF1/4(O)XPF1/4

desc: COUDE

1шт.

42

2184-1046D135

HOSE PF1/4-2500L

desc: TUYAU FLEXIBLE

1шт.

43

2184-1046D163

HOSE PF1/4-1330L

desc: TUYAU FLEXIBLE

1шт.

44

2184-1046D117

HOSE PF1/4-1700L

desc: TUYAU FLEXIBLE

1шт.

45

2184-1046D189

HOSE PF1/4-710L

desc: TUYAU FLEXIBLE

1шт.

46

2184-1046D76

HOSE PF1/4-1200L

desc: TUYAU FLEXIBLE

1шт.

47

2184-1046D35

HOSE PF1/4-680L

desc: TUYAU FLEXIBLE

1шт.
