Запчасти Doosan Daewoo LUBRICATION PIPING OPTION PARTS

-

2400-1875

LUBRICATION PIPING

SC: D

-2шт.

1

2182-1303A

PIPE

desc: TUYAU

1шт.

2

2182-1300

PIPE

desc: TUYAU

1шт.

3

2182-1667

PIPE

desc: TUYAU

1шт.

4

2183-3865A

PIPE

desc: TUYAU

1шт.

5

2183-3866A

PIPE

desc: TUYAU

1шт.

6

2181-1184

FITTING;PIPE

desc: RACCORD

9шт.

7

S6710102

FITTING

desc: GRAISSEUR

6шт.

8

2124-1006

CLAMP

desc: ATTACHE DE TUYAU

3шт.

9

S0558153

BOLT M10X1.5X30

desc: BOULON A 6 PANS

6шт.

10

2181-1110D1

ADAPTER PF1/4

desc: RACCORD

2шт.

11

2181-1111D1

ELBOW PF.PT1/4

desc: COUDE

2шт.

12

2181-1013

ADAPTER;S

desc: RACCORD

2шт.

13

2181-1110D30

ADAPTER PF1-PT2

desc: RACCORD

1шт.

14

2184-1026D42

HOSE PF1/4-800L

desc: TUYAU FLEXIBLE

2шт.

15

2184-1046D81

HOSE PF1/4-650L

desc: TUYAU FLEXIBLE

1шт.

16

2181-1923D9

ADAPTER PF1/4-M14X1.5

desc: RACCORD

1шт.

17

2124-1027D2

CLIP;PIPE

desc: ATTACHE

3шт.

18

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

3шт.

19

2181-1925

ELBOW

desc: COUDE

2шт.

20

2182-1666

PIPE

desc: TUYAU

1шт.
