Запчасти Doosan Daewoo REMOTE CONTROL VALVE(2) HYDRAULIC PARTS

-

2420-9292

REMOTE CONTROL VALVE

desc: MANIPULATEUR

1шт.

-

J24D2000

REMOTE CONTROL VALVE

desc: MANIPULATEUR

1шт.

1

J24D2001

CASING

desc: . CARTER

2шт.

2

J24D2002

PEDAL

desc: . PADALE

2шт.

3

J24D2003

COVER;PEDAL

desc: . COUVERCLE

2шт.

4

J24D2004

COVER

desc: . COUVERCLE

2шт.

5

DU1010

BUSH

desc: . DOUILLE

4шт.

6

J24D2005

CAM

desc: . CAMES

2шт.

7

J24D2006

BELLOWS

desc: . SOUFFLET

2шт.

8

J24D2007

SPOOL

desc: . TIROIR

4шт.

9

S090601

SHIM

desc: . CALE

12шт.

10

J24D2008

SPRING;SET

desc: . RESSORT

4шт.

11

J24D2009

SPRING

desc: . RESSORT

4шт.

12

J24D2010

SPRING;SET

desc: . RESSORT

4шт.

13

J24D2011

STOPPER

desc: . ARRET

4шт.

14

J24D2012

PLUG

desc: . BOUCHON

4шт.

15

P0020

O-RING P20

desc: . JOINT TORIQUE

4шт.

16

DSP10

SEAL;DUST

desc: . PARE-POUSSIERES

4шт.

17

RSY10

SEAL;ROD

desc: . JOINT

4шт.

18

J24D2013

SPRING

desc: . RESSORT

4шт.

19

J24D2014

ROD;PUSH

desc: . TIGE

4шт.

20

WBM0830

BOLT;WRENCH M8X30L

desc: . BOULON

4шт.

21

J24D2015

SCREW;SET

desc: . VIS

4шт.

22

HNM10

NUT M10

desc: . ECROU

4шт.

23

J24D2016

CHAFT;CAM

desc: . CAMES

2шт.

24

CBM0812

SCREW;SET M6X5L

desc: . VIS

2шт.

25

WBM1015

BOLT;WRENCH M10X15L

desc: . BOULON

4шт.

26

WPT18

PLUG PT1/8

desc: . BOUCHON

2шт.

27

J24D2017

SPACER

desc: . DOUILLE D'ECARTEMENT

1шт.

28

P0012

O-RING P12

desc: . JOINT TORIQUE

4шт.

29

WBM0845

BOLT;WRENCH M8X45L

desc: . BOULON

4шт.

30

WPT38

PLUG PT3/8

desc: . BOUCHON

2шт.
