Запчасти Doosan Daewoo ELECTRIC PARTS ENGINE PARTS

1

65.26201-7058

STARTER 24VX6.6KW

SERIAL: 500199

1шт.

1

65.26201-7123

STARTER 24VX6.6KW

SERIAL: 500200

1шт.

2

06.06175-8308

BOLT;STUD M12X30

desc: GOUJON

3шт.

3

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE A12

3шт.

4

06.11063-9216

BOLT;HEX. M12X1.5

desc: BOULON A 6 PANS

3шт.

4

2502-9003

ALTERNATOR

desc: ALTERNATEUR

1шт.

5

65.96801-0073

V-BELT 12.5X1035

desc: COURROIE

1шт.

5

65.96801-0072

V-BELT 12.5X1000

REP_PNO: 2106-1017D6

1шт.

5

65.96801-0118

V-BELT 12.5X1625

SERIAL: 960808

1шт.

5

65.96801-0120

V-BELT 1-A-1400

SERIAL: 5300

1шт.

6

65.19102-5032

BRACKET;ALTERNATOR MOUNTING

SERIAL: 960312

1шт.

6

65.19102-5045

BRACKET;ALTERNATOR MOUNTING

SERIAL: 960313

1шт.

7

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE. A10

2шт.

7

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE. A10

8

06.01283-7215

BOLT;HEX. M10X25

desc: BOULON A 6 PANS

2шт.

8

06.01913-3215

BOLT;HEX. M10X25

desc: BOULON A 6 PANS

2шт.

9

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE A8

2шт.

9

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE A8

10

06.01283-7114

BOLT;HEX. M8X22

desc: BOULON A 6 PANS

2шт.

10

06.01913-3114

BOLT;HEX. M8X22

desc: BOULON A 6 PANS

2шт.

11

65.19103-0066

SUPPORT;ALTERNATOR

desc: SUPPORT D'ALTERNATEUR

1шт.

12

06.01734-4411

BOLT;HEX. M14X1.5X30

desc: BOULON A 6 PANS

1шт.

13

06.16731-2110

WASHER;SPRING A14

desc: RONDELLE ELASTIQUE A14

1шт.

14

06.11063-9217

NUT;HEX. M14X1.5

desc: ECROU 6 PANS

1шт.

15

06.01493-4311

BOLT;HEX. M12X1.5X60

desc: BOULON A 6 PANS

1шт.

15

06.01943-3323

HEX. BOLT ASS'Y M12X1.5X60

desc: BOULON 6 PANS

1шт.

16

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE A12

1шт.

16

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE A12

17

65.19102-0056

BRACKET

SERIAL: 960312

1шт.

17

65.19102-5046

BRACKET

SERIAL: 960313

1шт.

18

65.27901-0005

GASKET(END COVER)

desc: JOINT

1шт.

19

65.91605-0009

COVER

desc: COUVERCLE

1шт.

20

06.56180-0708

RING;SEAL A6.5X11

desc: BAGUE D'ETANCHEITE

4шт.

21

06.02090-0308

BOLT;SOCKET HEAD M6X16

desc: BOULON 6 PANS CREUX

4шт.
