Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

1

65.03101-6501

CYLINDER HEAD ASS'Y(FRONT)

SERIAL: 400179

1шт.

1

65.03101-6501I

CYLINDER HEAD ASS'Y(FRONT)

SERIAL: 400180

1шт.

1

65.03101-0301

HEAD;CYLINDER(FRONT)

desc: TETE DE VERIN

1шт.

1

65.03101-0301U

HEAD;CYLINDER(FRONT)

desc: TETE DE VERIN

1шт.

1-1

06.15091-0322

PLUG;CORE D32

desc: . BOUCHON DE DESSABLAGE

2шт.

1-2

06.15091-0319

PLUG;CORE D28

desc: . BOUCHON DE DESSABLAGE

5шт.

1-3

06.15091-0317

PLUG;CORE D25

desc: . BOUCHON DE DESSABLAGE

3шт.

2

06.15091-0315

PLUG

desc: BOUCHON

2шт.

3

65.03201-1008

GUIDE;VALVE

desc: GUIDE DE SOUPAPE

12шт.

3

65.03203-1031

RING;VALVE SEAT(EXHAUST)

desc: BAGUE

6шт.

3

65.03203-1042

RING;VALVE SEAT(EXHAUST)

desc: BAGUE

6шт.

3

65.03203-1036

RING;VALVE SEAT(INTAKE)

desc: BAGUE

6шт.

3

65.03203-1041

RING;VALVE SEAT(INTAKE)

desc: BAGUE

6шт.

4

65.03101-6502

CYLINDER HEAD ASS'Y(REAR)

SERIAL: 400179

1шт.

4

65.03101-6502H

CYLINDER HEAD ASS'Y(REAR)

SERIAL: 400180

1шт.

4

65.03101-0302

HEAD;CYLINDER(REAR)

desc: TETE DE VERIN

1шт.

4

65.03101-0302U

HEAD;CYLINDER(REAR)

desc: TETE DE VERIN

1шт.

4

06.15091-0322

PLUG;CORE 32

desc: BOUCHON DE DESSABLAGE

2шт.

4

06.15091-0319

PLUG;CORE 28

desc: BOUCHON DE DESSABLAGE

5шт.

4

06.15091-0317

PLUG;CORE 25

desc: BOUCHON DE DESSABLAGE

3шт.

5

65.90020-0034

BOLT;CYLINDER HEAD

desc: BOULON A 6 PANS

28шт.

6

65.03901-0049

GASKET;CYLINDER HEAD(FRONT)

SERIAL: 400179

1шт.

6

65.03901-0051

GASKET;CYLINDER HEAD(FRONT)

SERIAL: 400180

1шт.

7

65.03901-0050

GASKET;CYLINDER HEAD(REAR)

SERIAL: 400179

1шт.

7

65.03901-0052

GASKET;CYLINDER HEAD(REAR)

SERIAL: 400180

1шт.

8

65.41520-0002

BRACKET;HANGER(FRONT)

desc: SUPPORT

1шт.

9

06.01494-4408

BOLT;HEX. M14X1.5X45

desc: BOULON A 6 PANS

1шт.

10

06.16731-2110

WASHER;SPRING A14

desc: RONDELLE ELASTIQUE A14

1шт.

11

06.01734-4411

BOLT;HEX. M14X1.5X30

desc: BOULON A 6 PANS

1шт.

12

06.16731-2108

WASHER;SPRING A10

SERIAL: 400179

1шт.

12

06.16731-2108

WASHER;SPRING A10

SERIAL: 400180

13

06.01283-7215

BOLT;HEX. M10X1.5

SERIAL: 400179

1шт.

13

06.01913-3215

HEX. BOLT ASS'Y M10X1.5

SERIAL: 400180

1шт.

14

65.91701-0275

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

15

65.03905-0014

GASKET;CYLINDER HEAD COVER

SERIAL: 400229

1шт.

15

65.03905-0018

GASKET;CYLINDER HEAD COVER

SERIAL: 400230

1шт.

16

65.03401-6020

CYLINDER HEAD COVER ASS'Y

ICA: I

1шт.

16

65.03401-6048

CYLINDER HEAD COVER ASS'Y

SERIAL: 9800001

1шт.

17

65.01810-5007

CAP;OIL FILLER ASS'Y

desc: . BOUCHON

1шт.

19

65.03905-0009

PACKING

desc: RONDELLE D'ETANCHEITE

6шт.

19

65.03905-0017A

PACKING

SERIAL: 400001

6шт.

20

65.90701-0052

WASHER

desc: RONDELLE

6шт.

21

65.90020-0012

BOLT;HEX

desc: BOULON A 6 PANS

6шт.

22

65.97871-0240

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

23

65.97801-0148

PLATE;CAUTION

desc: PLAQUE D'AVERTISSEMENT

1шт.

23

65.97801-0148

PLATE;CAUTION

desc: PLAQUE D'AVERTISSEMENT
