Запчасти Doosan Daewoo BEARING CASE ENGINE PARTS

-

65.11301-7005A

INJECTION DRIVE ASS'Y

desc: PIGNON D'ENTRAINEMENT DE POMPE D'I

1шт.

1

65.11309-0004

CASE;INJECTION PUMP BEARING

desc: . CARTER

1шт.

2

65.11301-0009

GEAR;INJECTION PUMP DRIVE

desc: . PIGNON D'ENTRAINEMENT DE POMPE D'

1шт.

3

65.11308-0001

SHIM 0.5§®

desc: . CALE 0.5mm

1шт.

3

65.11308-0002

SHIM 0.2§®

desc: . CALE 0.2mm

1шт.

3

65.11308-0003

SHIM 0.15§®

desc: . CALE 0.15mm

1шт.

3

65.11308-0004

SHIM 0.1§®

desc: . CALE 0.1mm

1шт.

4

65.11312-0007

COVER;INJECTION PUMP BEARING CASE

desc: . COUVERCLE

1шт.

5

06.16731-2107

WASHER;SPRING A8

desc: . RONDELLE ELASTIQUE

3шт.

5

06.16731-2107

WASHER;SPRING A8

desc: . RONDELLE ELASTIQUE

6

06.01283-7116

BOLT;HEX. M8X28

SERIAL: 940222

3шт.

6

06.01913-3116

BOLT;HEX. M8X28

SERIAL: 940223

3шт.

7

06.29141-0215

KEY;WOODRUFF 6X22

desc: . CLAVETTE WOODRUFF

2шт.

8

65.90501-0022

NUT;HEX. M24X1.5

SERIAL: 970228

1шт.

8

65.11250-4329

NUT;HEX. M24X1.5

SERIAL: 970229

1шт.

9

06.16050-0316

WASHER;LOCK

desc: . RONDELLE FREIN

1шт.

10

65.11302-0006

SHAFT;INJECTION PUMP DRIVE

desc: . ARBRE D'ENTRAINEMENT DE POMPE D'I

1шт.

11

06.32092-0307

BEARING;TAPER ROLLER

desc: . ROULEMENT A ROULEAUX CONIQUES

2шт.

12

65.01510-0151

SEAL;OIL A32X52X9

desc: . JOINT D'HUILE

1шт.

13

06.22022-0912

PIN;DOWEL 6m6X20

desc: GOUPILLE D'AJUSTAGE

2шт.

14

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE. A10

5шт.

14

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE. A10

1шт.

15

06.01014-9219

BOLT;HEX. M10X70

ICA: I

2шт.

15

06.01914-3225

HEX. BOLT ASS'Y M10X70

SERIAL: 9400001

2шт.

15-1

06.01013-9213

BOLT;HEX. M10X40

desc: BOULON A 6 PANS

2шт.

16

06.06225-0809

BOLT;STUD M10X35

desc: GOUJON

1шт.

17

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS

1шт.

18

65.11902-0012

GASKET

SERIAL: 500129

1шт.

18

65.11902-0016

GASKET

SERIAL: 500130

1шт.
