Запчасти Doosan Daewoo MAIN PIPING(3)-DX28 BODY PARTS

-

2400-1541

MAIN PIPING

SERIAL: 5001-5674

-2шт.

-

2400-1541A

MAIN PIPING

SERIAL: 5675

-2шт.

6

2180-1026D19

O-RING SAE1"

SERIAL: 5001-5674

8шт.

6

2180-1026D19

O-RING SAE1"

SERIAL: 5675

10шт.

13

2184-1100D36

HOSE 1"-2000L

SERIAL: 5001-5674

1шт.

13

2184-1100D103

HOSE 1"-2100L

SERIAL: 5675-6419

1шт.

13

2184-1100D36

HOSE 1"-2100L

SERIAL: 6420-6519

1шт.

13

2184-1100D119

HOSE 1"-2000L

SERIAL: 6520

1шт.

14

2184-1198D15

HOSE 1/2"-600L

desc: TUYAU FLEXIBLE

1шт.

16

2184-1100D41

HOSE 1"-1850L

desc: TUYAU FLEXIBLE

1шт.

19

2184-1100D37

HOSE 1"-1900L

SERIAL: 5001-5674

1шт.

19

2184-1100D36

HOSE 1"-2000L

SERIAL: 5675

1шт.

20

2184-1100D16

HOSE 1"-1750L

desc: TUYAU FLEXIBLE

1шт.

25

2181-9083

FLANGE;SPLIT 1" STANDARD

SERIAL: 5001-5674

3шт.

25

2181-9083

FLANGE;SPLIT 1" STANDARD

SERIAL: 5675

2шт.

26

S2212261

BOLT;SOCKET M10X1.5X30

SERIAL: 5001-5674

32шт.

26

S2212261

BOLT;SOCKET M10X1.5X30

SERIAL: 5675

30шт.

32

S8030081

O-RING F08

desc: JOINT TORIQUE

2шт.

33

2181-9078

FLANGE;SPLIT (1"-STANDARD)

SERIAL: 5001-5674

13шт.

33

2181-9078

FLANGE;SPLIT (1"-STANDARD)

SERIAL: 5675

14шт.

37

2181-4133D3

ADAPTER PF(O)1/2-UNF13/16

desc: RACCORD ADAPTATEUR

1шт.

40

S8000181

O-RING P18

REP_PNO: 8202-014

2шт.

43

2181-4133D3

ADAPTER PF(O)1/2-UNF13/16

desc: RACCORD ADAPTATEUR

1шт.

45

2181-2614

BLOCK;SPACER

SERIAL: 5675

2шт.

47

S2213061

BOLT;SOCKET M10X1.5X70

SERIAL: 5675

8шт.
