Запчасти Doosan Daewoo ELECTRIC PARTS(4)-ELECTRIC BOX BODY PARTS

-

2500-1085

ELECTRIC PARTS

SERIAL: 5001

-2шт.

5

2510-1006

FUSE BOX ASS'Y

desc: ENSEMBLE BOITE A FUSIBLES

1шт.

5A

2527-1016

FUSE;BLADE 10A

desc: . FUSIBLE

10шт.

5B

2527-1017

FUSE;BLADE 15A

desc: . FUSIBLE

8шт.

6

S3450983

SCREW M6X1.0X20

desc: VIS M6X1.0X20

2шт.

7

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

8

2190-1919

PLATE;NAME(FUSE BOX)

desc: PLAQUE D'IDENTIFICATION

1шт.

25

2543-1022

CONTROLLER;EPOS-3

desc: MODULE DE COMMANDE

1шт.

26

S0511753

BOLT M10X1.5X18

desc: BOULON A 6 PANS

4шт.

27

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

28

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE M10

4шт.

29

2543-1020A

CONTROLLER;THROTTLE

SERIAL: 5001-5674

1шт.

29

2543-1020B

CONTROLLER;THROTTLE

SERIAL: 5675

1шт.

30

S4012333

NUT M6X1.0

desc: ECROU

4шт.

31

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

4шт.

32

2523-9003

CONTROLLER;STARTER

SERIAL: 5001-5299

1шт.

32

2523-9004A

CONTROLLER;STARTER

SERIAL: 5300

1шт.

33

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

2шт.

34

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

35

2537-9002

TIMER;WIPER

desc: TIMER ESSUIE-GLACE

1шт.

36

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

2шт.

37

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

38

2531-9001

CONVERTER;DC-DC

SERIAL: 5001-5129

1шт.

38

2531-1003

CONVERTER;DC-DC

SERIAL: 5130

1шт.

39

S3450953

SCREW M6X1.0X12

desc: VIS M6X1.0X12

2шт.

40

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

41

2516-1102A

BUZZER;PILOT

desc: COMMANDE VIBREUR

1шт.

42

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

2шт.

43

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

44

2523-9007

CONTROLLER;PREHEAT

desc: COMMANDE PRECHAUFFAGE

1шт.

45

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

2шт.

46

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

47

2544-9020

RELAY;LAMP

SERIAL: 5001-5189

1шт.

47

2544-9028

RELAY;LAMP

SERIAL: 5190

1шт.

47

2544-9029

RELAY;LAMP

desc: RELAIS

1шт.

48

2544-9020

RELAY;WIPER

SERIAL: 5001-5189

1шт.

48

2544-9028

RELAY;WIPER

SERIAL: 5190

1шт.

48

2544-9029

RELAY;WIPER

desc: RELAIS

1шт.

49

2544-9020

RELAY;HORN

SERIAL: 5001-5189

1шт.

49

2544-9028

RELAY;HORN

SERIAL: 5190

1шт.

49

2544-9029

RELAY;HORN

desc: RELAIS

1шт.

50

2544-9020

RELAY;ENGINE STOP

SERIAL: 5001-5189

1шт.

50

2544-9028

RELAY;ENGINE STOP

SERIAL: 5190

1шт.

50

2544-9029

RELAY;ENGINE STOP

desc: RELAIS

1шт.

51

2190-2037D1

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

54

2530-1390

HARNESS;ELECTRIC BOX

desc: FAISCEAU BOITIER ELECTRIQUE

1шт.

55

2530-1395

HARNESS;CABIN

SERIAL: 5001-5194

1шт.

55

2530-1395A

HARNESS;CABIN

SERIAL: 5195-5444

1шт.

55

2530-1395B

HARNESS;CABIN

SERIAL: 5445

1шт.

57

S3450823

SCREW M5X0.8X10

desc: VIS

2шт.

58

S5102303

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE M5

2шт.

59

2124-1509D2

CLIP D18/M8

desc: CLIP

2шт.

60

2124-1509D4

CLIP D24/M8

desc: CLIP

4шт.

61

2124-1509D6

CLIP D42/M8

desc: CLIP

2шт.

62

S4012533

NUT M8X1.25

desc: ECROU

7шт.

63

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

7шт.

64

S5010313

WASHER;PLAIN M6

desc: RONDELLE PLATE

4шт.
