Запчасти Doosan Daewoo AIRCONDITIONER BODY PARTS

-

2920-1037

COOLER & HEATER ASS'Y

SERIAL: 5001

-2шт.

1

2208-6011

COMPRESSOR V-5. A-TYPE

SERIAL: 5001-5119

1шт.

1

2208-6011A

COMPRESSOR V-5. A-TYPE

SERIAL: 5120-5426

1шт.

1

2208-6011B

COMPRESSOR V-5. A-TYPE

SERIAL: 5427

1шт.

2

S0509053

BOLT M8X1.25X25

SERIAL: 5001-6219

6шт.

2

S0509053

BOLT M8X1.25X25

SERIAL: 6220

2шт.

3

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

10шт.

4

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

6шт.

5

2185-1352A

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE COMPRESSEUR

1шт.

6

S2212361

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS CREUX

3шт.

7

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

3шт.

8

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE M10

3шт.

9

2520-6003

CONDENSER ASS'Y

SERIAL: 5001-6845

1шт.

9

2520-6003A

CONDENSER ASS'Y

SERIAL: 6846

1шт.

10

2195-3602A

BRACKET;CONDENSER(L)

SERIAL: 5001-6219

1шт.

10

2197-1901

BRACKET;CONDENSER(L)

SERIAL: 6220

1шт.

11

S0553553

BOLT M6X1.0X45

desc: BOULON A 6 PANS

4шт.

12

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

6шт.

13

S5010313

WASHER;PLAIN M6

desc: RONDELLE PLATE

6шт.

14

S4012333

NUT M6X1.0

desc: ECROU

4шт.

15

2185-1371D2

HOSE;LIQUID(1) L2500

SERIAL: 5001-6674

1шт.

15

2185-1371D3

HOSE;LIQUID(1) L2700

SERIAL: 6675

1шт.

16

2185-1369D6

HOSE;LIQUID(2) L4800

desc: TUYAU FLEXIBLE

1шт.

17

2204-6032

DRIER;RECEIVER

desc: RESERVOIR DESSICATEUR

1шт.

18

2514-6001

HOLDER;DRIER

desc: ENSEMBLE SUPPORT

1шт.

19

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

2шт.

20

2920-9031

UNIT;AIR HANDLING

SERIAL: 5001-5426

1шт.

20

2920-9031B

UNIT;AIR HANDLING

SERIAL: 5427

1шт.

21

2191-1374D12

PLATE

desc: PLAQUE

4шт.

22

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

23

2549-1132D2

SWITCH;AIRCON

desc: INTERRUPTEUR

1шт.

24

2543-9027

CONTROLLER;AIRCON

desc: MODULE DE COMMANDE

1шт.

25

S3450583

SCREW M4X0.7X12

desc: VIS

2шт.

26

S5100103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE M4

2шт.

31

2124-1509D6

CLIP D42/M8

desc: CLIP

3шт.

32

S4012533

NUT M8X1.25

desc: ECROU

3шт.

33

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

3шт.

34

2124-1084D3

CLIP;BAND L250

desc: CLIP

15шт.

35

S2209063

BOLT;SOCKET M8X1.25X25

desc: BOULON A 6 PANS CREUX

4шт.

36

2114-1058D29

WASHER D42/M8

desc: RONDELLE

3шт.

37

2195-3875

BRACKET;CONDENSER(R)

SERIAL: 5001-6219

1шт.

37

2197-1902

BRACKET;CONDENSER(R)

SERIAL: 6220

1шт.

39

S0508853

BOLT M8X1.25X20

SERIAL: 6220

4шт.
