Запчасти Doosan Daewoo SEALED TRACK SHOE-800G OPTION PARTS

-

273-00090

SEALED TRACK SHOE ASS'Y

SC: D

1шт.

1

273-00086

TRACK SHOE ASS'Y-800G

desc: TRAIN A MAILLON

2шт.

1-1

272-00046

TRACK LINK ASS'Y

desc: . TRAIN A MAILLON

1шт.

1-1A

2272-6104R

LINK(R..H)

desc: .. PIECE DE JONCTION

50шт.

1-1B

2272-6104L

LINK(L..H)

desc: .. PIECE DE JONCTION

50шт.

1-1C

2272-6105R

LINK;MASTER(R..H)

desc: .. PIECE DE JONCTION

1шт.

1-1D

2272-6105L

LINK;MASTER(L..H)

desc: .. PIECE DE JONCTION

1шт.

1-1E

2123-6060

PIN

desc: .. BROCHE

50шт.

1-1F

110-00226

BUSHING

desc: .. DOUILLE

50шт.

1-1G

2123-6061

PIN;MASTER

desc: .. BROCHE PRINCIPALE

1шт.

1-1H

2110-6052

BUSHING;MASTER

desc: .. DOUILLE PRINCIPALE

1шт.

1-1I

180-00441

SEAL;DUST

desc: .. JOINT

100шт.

1-1J

2114-6035

SPACER

desc: .. ENTERTOISE

2шт.

1-1K

2123-6062

PIN

desc: .. BROCHE

1шт.

1-2

2273-6040D3

SHOE;800G

desc: . SABOT

51шт.

1-3

2120-6017

BOLT

desc: . BOULON A 6PANS

204шт.

1-4

2121-6017

NUT

desc: . ECROU

204шт.

2

2625-1220D3

BRACKET

desc: SUPPORT

4шт.

4

S0558253

BOLT

desc: BOULON A 6PANS

16шт.

5

S5102603

WASHER;SPRING(M10)

desc: RONDELLE ELASTIQUE

16шт.
