Запчасти Doosan Daewoo ELECTRIC WIRING(2)-ENGINE UPPER STRUCTURE

-

500-00139

ELECTRIC WIRING(2)

SC: D

-2шт.

3

530-00190A

HARNESS;ENGINE

desc: FAISCEAU

1шт.

3A

2548-1027

DIODE ASS'Y 3A

desc: . DIODE

2шт.

14

S0511653

BOLT M10X1.5X16

desc: BOULON A 6 PANS

1шт.

15

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

16

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

17

2195-3500

BRACKET;HOUSING

desc: SUPPORT

1шт.

18

S3450953

SCREW M6X1.0X12

desc: VIS

1шт.

19

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

1шт.

20

2197-1660

BRACKET;HOUSING W15

desc: SUPPORT

1шт.

21

2197-1661

BRACKET;HOUSING W9

desc: SUPPORT

2шт.

22

2120-2235

BOLT;STUD M10X1.25X15/M

desc: BOULON A 6 PANS

5шт.

23

2121-1305

NUT M8X1.25

desc: ECROU

6шт.

24

2124-1509D1

CLIP D12/M8

desc: ATTACHE

4шт.

25

124-00208D2

CLIP D14/M8

desc: ATTACHE

6шт.

26

124-00208D3

CLIP D20/M8

desc: ATTACHE

9шт.

29

120-00276

BOLT M8X1.25X12

desc: BOULON A 6 PANS

10шт.

30

2124-1353D8

CLIP D22/M12

desc: ATTACHE

1шт.
