Запчасти Doosan Daewoo AIR CLEANER ASSY UPPER STRUCTURE

-

204-00048A

AIR CLEANER ASS'Y

SERIAL: 50001-50160

-2шт.

-

204-00048B

AIR CLEANER ASS'Y

SERIAL: 50161

-2шт.

1

2204-2012A

CLEANER;AIR

desc: FILTRE A AIR

1шт.

2

2124-1552A

BAND;AIR CLEANER

desc: ATTACHE DE TUYAU

2шт.

3

2120-2196D2

BOLT;SET M10X1.5X25

desc: BOULON A 6 PANS

10шт.

4

2204-9032A

PRE-CLEANER

SERIAL: 50001-50070

1шт.

4

2204-9032

PRE-CLEANER

SERIAL: 50071-50175

1шт.

4

K1017883

PRE-CLEANER

SERIAL: 50176

1шт.

5

185-00309

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

6

193-00584

PIPE;AIR

desc: CONDUITE

1шт.

7

185-00310

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

8

193-00814

PIPE;AIR

desc: CONDUITE

1шт.

9

185-00311A

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

10

621-02040C

COVER

SERIAL: 50001-50120

1шт.

10

621-02040E

COVER

SERIAL: 50121

1шт.

11

170-00004

INDICATOR

desc: INDICATEUR

1шт.

12

2181-2690

ADAPTER;FILTER

desc: RACCORD ADAPTEUR

1шт.

13

185-00312

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

14

S8510143

CLAMP;HOSE

desc: COLLIER

5шт.

15

S8510092

CLAMP;HOSE

desc: COLLIER

1шт.

16

S8510168

CLAMP;HOSE

desc: COLLIER

2шт.

18

S5010613

WASHER M10

desc: RONDELLE PLATE

2шт.

19

S5102603

WASHER M10

desc: RONDELLE ELASTIQUE

2шт.

20

2120-2196D9

BOLT;SET M12X1.75X25

desc: BOULON A 6 PANS

13шт.

23

S4012633

NUT M10X1.5

desc: ECROU

2шт.

24

2120-2165

BOLT

desc: BOULON A 6 PANS

2шт.

25

621-02216

COVER

desc: COVERCLE

1шт.
