Запчасти Doosan Daewoo TRACK SHOE ASSY-600G UNDER STRUCTURE

-

604-00011A

TRACK ASS'Y

SERIAL: 50001-50200

-2шт.

-

604-00011B

TRACK ASS'Y

SERIAL: 50201

-2шт.

8

273-00008

TRACK SHOE ASS'Y

desc: ENSEMBLE MAILLON DE CHAINES

2шт.

8-1

273-00009

TRACK LINK ASS'Y

desc: . ENSEMBLE MAILLON DE CHAINES

1шт.

8-1A

2272-6104R

LINK;TRACK(RH)

desc: .. PIECE DE JONCTION

50шт.

8-1B

2272-6104L

LINK;TRACK(LH)

desc: .. PIECE DE JONCTION

50шт.

8-1C

2272-6105R

LINK;MASTER(RH)

desc: .. PIECE DE JONCTION

1шт.

8-1D

2272-6105L

LINK;MASTER(LH)

desc: .. PIECE DE JONCTION

1шт.

8-1E

2123-6060

PIN

desc: .. GOUPILLE

50шт.

8-1F

2114-6035

SPACER

desc: .. ENTERTOISE

2шт.

8-1G

2123-6062

PIN;SMALL

desc: .. GOUPILLE

1шт.

8-1H

2110-6051

BUSHING

desc: .. DOUILLE

50шт.

8-1I

2110-6052

BUSHING;MASTER

desc: .. MANCHON

1шт.

8-1J

2123-6061

PIN;MASTER

desc: .. BROCHE

1шт.

8-2

2273-6040D1

SHOE 600MM

desc: . SABOT

51шт.

8-3

2120-6017

BOLT

desc: . BOULON A 6 PANS

204шт.

8-4

2121-6017

NUT

desc: . ECROU

204шт.
