Запчасти Doosan Daewoo TRAVEL REDUCTION GEAR HYDRAULIC PARTS

-

401-00023A

TRAVEL DEVICE

desc: MOTEUR DE TRANSLATION

1шт.

-

K9000381

REDUCTION GEAR

desc: MOTEUR DE TRANSLATION

1шт.

1

K9000382

COVER

desc: COUVERCLE

1шт.

2

K9000383

CARRIER 1

desc: PORTE-SATELLITES

1шт.

3

K9000384

PIN;CARRIER 1

desc: BOUCHON PORTE-SATELLITES

3шт.

4

109-00104

BEARING;NEEDLE

desc: ROULEMENT A ROULEAUX

3шт.

5

K9000385

WASHER;THRUST

desc: RONDELLE DE BUTEE

6шт.

6

K9000386

GEAR;PLANETARY 1

desc: REDUCTEUR DE PIGNON

3шт.

7

S5740670

PIN;SPRING

desc: RESSORT

3шт.

8

2412-7006

PLATE;THRUST

desc: PLAQUE

1шт.

9

K9000387

GEAR;SUN 1

desc: PIGNON

1шт.

10

K9000388

GEAR;SUN 2

desc: PIGNON

1шт.

11

K9000389

CARRIER 2

desc: PORTE-SATELLITES

1шт.

12

K9000390

PIN;CARRIER 2

desc: BOUCHON PORTE-SATELLITES

4шт.

13

109-00105

BEARING;NEEDLE

desc: ROULEMENT A ROULEAUX

4шт.

14

K9000391

GEAR;PLANETARY 2

desc: REDUCTEUR DE PIGNON

4шт.

15

S5740960

PIN;SPRING

desc: RESSORT

4шт.

16

114-00234

WASHER;THRUST

desc: RONDELLE DE BUTEE

8шт.

17

K9000392

GEAR;RING

desc: PIGNON

1шт.

18

K9000393

HOUSING

desc: CARTER

1шт.

19

109-00106

BEARING;BALL

desc: PALIER

2шт.

20

K9000394

SHIM KIT

desc: CALE

1шт.

21

114-00236

WASHER;LOCK

desc: RONDELLE D'ARRET

2шт.

22

411-00006

RING;SUPPORT

desc: BAGUE D'ARRET

1шт.

23

180-00210

SEAL;FLOATING

desc: PARE-POUSSIERES

1шт.

24

S2212271

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

15шт.

25

S2222471

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

22шт.

26

2181-1116D5

PLUG;CAP

desc: BOUCHON

2шт.
