Запчасти Doosan Daewoo BUCKET ASSY-0.95M©ш FRONT ATTACHMENTS

-

704-00024A

BUCKET ASS'Y-0.95§©

SERIAL: 50001-50050

1шт.

-

704-00024B

BUCKET ASS'Y-0.95§©

SERIAL: 50051

1шт.

1

-

BUCKET-0.95§©

SC: D

1шт.

1A

2713-1218

ADAPTER;TOOTH

desc: . RACCORD

5шт.

2

2713-1217

POINT;TOOTH

SERIAL: 50001-50050

5шт.

2

K1000344

POINT;TOOTH

SERIAL: 50051

5шт.

3

2705-1020

PIN;LOCKING

desc: BROCHE DE BLOCAGE

5шт.

4

2114-1848A

WASHER;LOCKING

desc: RONDELLE D'ARRET

5шт.

5

2713-1059A

CUTTER;SIDE(RH)

desc: COUTEAU LATERAL

1шт.

6

2713-1060A

CUTTER;SIDE(LH)

desc: COUTEAU LATERAL

1шт.

7

S0574761

BOLT M24X3.0X70

desc: BOULON A 6 PANS

10шт.

8

S4013333

NUT M24X3.0

desc: ECROU

10шт.

9

2114-1831

WASHER;HARDEN

desc: RONDELLE ELASTIQUE

10шт.
