Запчасти Doosan Daewoo LUBRICATION PIPING-BOOM 10M OPTION PARTS

-

9400-1152

LUBRICATION PIPING

SC: D

-2шт.

1

2181-1925

ELBOW PT 1/8-M14X1.5

desc: COUDE

2шт.

2

S6710041

NIPLE;GREASE

desc: GRAISSEUR

5шт.

3

181-00103

REDUCER PF1/4-PF1/8

desc: REDUCTEUR

3шт.

4

121-00006

NUT

desc: ECROU

3шт.

5

2184-1045D131

HOSE PF1/4-2700L

desc: TUYAU FLEXIBLE

1шт.

6

3184-1045D180

HOSE PF1/4-7100L

desc: TUYAU FLEXIBLE

1шт.

7

2184-1045D127

HOSE PF1/4-2600L

desc: TUYAU FLEXIBLE

1шт.

8

S0511553

BOLT M10X1.5X14

desc: BOULON A 6 PANS

12шт.

9

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

12шт.

10

124-00014

CLAMP;PIPE

desc: ATTACHE DE TUYAU

3шт.

11

2181-1110D30

ADAPTER PF1/4-PT1/8

desc: RACCORD ADAPTATEUR

3шт.

12

S3524403

PLUG;DRAIN

desc: BOUCHON

1шт.

13

181-00525

REDUCER PF1/4-M14X1.5

desc: REDUCTEUR

2шт.

14

S4032833

NUT M14X1.5

desc: ECROU

2шт.

15

140-00766

PIPE

desc: TUYAU

1шт.

16

140-00767

PIPE

desc: TUYAU

1шт.

17

9124-1012

CLAMP

desc: ATTACHE DE TUYAU

6шт.
