Запчасти Doosan Daewoo OIL PIPE & OIL PAN ENGINE PARTS

19A
18
25
27
33
19
22
32
16
30
28
16
21
20
28
29
15
23
31
26
17
17
14
1
2
8
11
7
8
5
6
9
3
13
10
9
12
4
10
19B
17A
17A

Артикул

Название

Примечание

Количество

1

65.05801-5194A

OIL PAN ASS'Y

desc: CARTER DE HUILE

1шт.

2

65.05904A0016

GASKET(OIL PAN)

desc: JOINT DE CARTER D'HUILE

1шт.

3

65.90001-6005

BOLT;SOCKET HEAD

desc: BOULON A 6 PANS CREUX

2шт.

4

06.01913-3115

BOLT;HEX. M8X1.25X25

desc: BOULON A 6 PANS

25шт.

5

65.90001-6006

BOLT;SOCKET HEAD M8X25

desc: BOULON A 6 PANS CREUX

10шт.

6

65.05806-5096A

TUBE;GUIDE

desc: TUYAU

1шт.

7

06.01923-3112

BOLT;HEX. M8X1.25X18

desc: BOULON A 6 PANS

1шт.

8

65.05909-0013

WASHER;OIL PAN

desc: RODELLE

2шт.

9

65.05909-0014

WASHER;OIL PAN

desc: RODELLE

2шт.

10

65.05909-0012

WASHER;OIL PAN

desc: RODELLE

9шт.

11

65.05909-0037

WASHER;OIL PAN

desc: RODELLE

1шт.

12

65.90310-0144

SCREW. PLUG M30X15

desc: VIS

1шт.

13

06.56190-0732

RING;SEAL A30X36

desc: CONTACT DE NIVEAU D'HUILE

1шт.

14

65.05805-5186A

GAUGE;OIL LEVEL

desc: GAUGE

1шт.

15

65.05701-5153

OIL PIPE ASS'Y(O/PЎЖC/F)

desc: ENSEMBLE CONDUITES D'HUILE(CARTER-B

1шт.

16

65.96601-0050

GASKET 22X44X1

desc: JOINT

4шт.

17

06.01283-7113

BOLT;HEX. M8X1.25X20

desc: BOULON A 6 PANS

4шт.

17A

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

4шт.

18

65.05903B0003

GASKET(CONNECTING FLANGE)

desc: JOINT

1шт.

19

65.05715-5001

CONNECTING FLANGE ASS'Y

desc: ENSEMBLE BRIDE DE RACCORDEMENT

1шт.

19A

06.15010-2311

WASHER

desc: RONDELLE

2шт.

19B

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

20

06.02090-0422

BOLT;SOCKET HEAD M8X65

desc: BOULON A 6 PANS CREUX

2шт.

21

65.05701-5230

OIL PIPE ASS'Y(C/F-BLOCK)

desc: ENSEMBLE CONDUITE D'HUILE(BRIDE-BLO

1шт.

22

65.90001-6006

BOLT;SOCKET HEAD M8X25

desc: BOULON A 6 PANS CREUX

2шт.

23

06.01923-3113

BOLT A'SSY M8X20

desc: BOULON A 6 PANS

2шт.

25

65.05701-6039B

OIL SUCTION PIPE ASS'Y

desc: CONDUITES DE HUILE

1шт.

26

65.05701-5203B

OIL SUCTION PIPE ASS'Y

desc: . CONDUITES DE HUILE

1шт.

27

65.05740-0015

HOLDER;OIL SUCTION PIPE

desc: . SUPPORT

1шт.

28

06.15010-2311

WASHER

desc: . RONDELLE

2шт.

29

06.01283-7114

BOLT;HEX. M8X1.25X22

desc: . BOULON A 6 PANS

1шт.

30

65.90510-0012

NUT;CLEVELOC M8

desc: . ECROU DE BLOCAGE

1шт.

31

65.96601B0019

GASKET(OIL SUCTION PIPE)

desc: JOINT(TUBE D'ASPIRATION D'HUILE)

1шт.

32

06.01923-3113

BOLT;HEX. M8X1.25X20

desc: BOULON A 6 PANS

2шт.

33

06.01923-3111

BOLT;HEX. M8X16

desc: BOULON A 6 PANS

1шт.

Выбрано товаров: 35
