Запчасти Doosan Daewoo OIL COOLER ENGINE PARTS

8C
21
20
2
22
1
5
4
3
18
13
14
11
15
16
12
17
19
6
9
6
7
8
8
10
8A
8B

Артикул

Название

Примечание

Количество

|$1

65.05601-7138

OIL COOLER ASS'Y

SERIAL: 000901

1шт.

|$2

65.05601-7138A

OIL COOLER ASS'Y

SERIAL: 000902

1шт.

1

65.05902A0011

GASKET;OIL COOLER HOUSING

desc: JOINT

1шт.

2

65.05604-5030

HOUSING;OIL COOLER

desc: . CARTER

1шт.

3

06.15030-0513

WASHER;PLAIN

desc: . RONDELLE

4шт.

4

06.16110-0106

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

4шт.

5

06.02090-0418

BOLT;SOCKET HEAD M8X45

desc: . BOULON 6 PANS

4шт.

6

65.96601A0018

GASKET;OIL COOLER

desc: . JOINT(REFROIDISSEUR D'HUILE)

2шт.

7

65.05606-5020

ELEMENT;OIL COOLER

desc: . ELEMENTRE

1шт.

8

65.05605-6006

COVER;OIL COOLER

SERIAL: 000901

1шт.

8

REP_PNO: 65.06301-0160

-1шт.

8

REP_PNO: 65.96601-0029

-1шт.

8

REP_PNO: 06.01913-3112

-1шт.

8

65.05605-0028

COVER;OIL COOLER

SERIAL: 000902

1шт.

8A

65.06301-0160

PIPE;COOLING WATER

SERIAL: 000902

1шт.

8B

65.96601-0029

GASKET;FLANGE

SERIAL: 000902

1шт.

8C

06.01923-3112

BOLT ASS'Y M8X18

SERIAL: 000902

4шт.

9

65.05902A0008

GASKET;OIL COOLER

desc: . JOINT(COUVERCLE DE REFROIDISSEUR

1шт.

10

06.01923-3126

BOLT;HEX. M8X75

desc: . BOULON A 6 PANS

8шт.

11

06.56190-0718

RING;SEAL

desc: . BAGUE D'ETANCHEITE

1шт.

12

65.90310-0136

SCREW;PLUG

desc: . BOUCHON A VIS

1шт.

13

06.31641-0429

BALL;BY-PASS

desc: . BILLE DE BY-PASS

1шт.

14

65.97601-0004

SPRING

desc: . RESSORT

1шт.

15

65.05611-0001

PIN

desc: . BROCHE

1шт.

16

06.56190-0728

RING;SEAL

desc: . BAGUE D'ETANCHEITE

1шт.

17

65.90310-0003

SCREW;PLUG M26X1.5

desc: . BOUCHON FILETE

1шт.

18

65.90001-6011

BOLT ASS'Y M10X70

desc: BOULON A 6 PANS

2шт.

19

06.01924-3225

BOLT ASS'Y M10X70

desc: BOULON A 6 PANS

2шт.

20

65.96601-0347

GASKET

desc: JOINT

1шт.

21

65.91605-0110

COVER;BLIND

desc: COUVERCLE

1шт.

22

06.01913-3112

BOLT ASS'Y M8X18

desc: BOULON A 6 PANS

4шт.

Выбрано товаров: 31
