Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

1

65.03101-6495J

CYLINDER HEAD ASS'Y

SERIAL: 001013

3шт.

1

65.03101-6495M

CYLINDER HEAD ASS'Y

SERIAL: 011211

3шт.

1

65.03101-6495N

CYLINDER HEAD ASS'Y

SERIAL: 011212

3шт.

2

65.03101-0295P

HEAD;CYLINDER

SERIAL: 001013

1шт.

2

65.03101-0295R

HEAD;CYLINDER

SERIAL: 011211

1шт.

2

65.03101-0295S

HEAD;CYLINDER

SERIAL: 011212

1шт.

3

65.03201-1011

GUIDE;VALVE

SC: B

4шт.

4

65.03203-1028D

RING;VALVE SEAT(EXHAUST)

SC: B

2шт.

5

65.03203-1029G

RING;VALVE SEAT(INTAKE)

SC: B

2шт.

6

06.15091-0319

PLUG;CORE

desc: . BOUCHON

7шт.

7

06.22022-0907

PIN;DOWEL

desc: GOUJON

6шт.

8

65.03901-0058

GASKET;CYLINDER HEAD

desc: JOINT

3шт.

9

65.90020-0070

BOLT;CYLINDER HEAD

desc: BOULON A 6 PANS

24шт.

10

06.06226-0808

BOLT;STUD M10X30

desc: BOULON A 6 PANS

6шт.

11

65.90201-0049

BOLT;STUD M12X1.5X35

desc: BOULON A 6 PANS

6шт.

13

65.03401-0021H

COVER;CYLINDER HEAD

desc: COUVERCLE

1шт.

14

65.03401-0056

COVER;CYLINDER HEAD

SERIAL: 990524

1шт.

14

65.03401-0056A

COVER;CYLINDER HEAD

SERIAL: 990525

1шт.

15

65.03401-6044B

COVER;CYLINDER HEAD

desc: COUVERCLE

1шт.

16

65.03905-0022

GASKET

desc: JOINT

3шт.

17

65.90020-0073

BOLT;COLLARED HEX

SERIAL: 990525

6шт.

18

65.90701-0202

WASHER

SERIAL: 990525

6шт.

19

65.03905-0023

GASKET;CYLINDER HEAD

SERIAL: 990525

6шт.

20

65.01810-5007

OIL FILLER CAP ASS'Y

desc: CHAPEAU

1шт.

21

65.01801-5095A

HOUSING;BREATHER

SERIAL: 001101

1шт.

21

65.01801-5099

HOUSING;BREATHER

SERIAL: 010622

1шт.

21

65.01801-5099A

HOUSING;BREATHER

SERIAL: 010623

1шт.

22

65.96501-0033B

O-RING

desc: JOINT TORIQUE

1шт.

23

06.01923-3111

BOLT ASS'Y M8X16

SERIAL: 001101

3шт.

23

06.01923-3113

BOLT ASS'Y M8X20

SERIAL: 001102

3шт.

24

06.67020-0105

CLAMP

desc: COLLIER

1шт.

25

65.97401-0164

CLIP;HOSE

SERIAL: 991230

1шт.

25

65.97401-0142

CLIP;HOSE

SERIAL: 991231

1шт.

26

65.96301-0294

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.
