Запчасти Doosan Daewoo MAIN FRAME BODY PARTS

-

9600-1009B

FRAME ASS'Y

SC: D

-2шт.

1

603-00008B

FRAME;MAIN

desc: CHASSIS

1шт.

2

9624-6018

WEIGHT;COUNTER(4.5T)

SERIAL: 1-50175

1шт.

2

624-00008

WEIGHT;COUNTER(4.5T)

SERIAL: 50176-50195

1шт.

2

9624-1013

WEIGHT;COUNTER(4.5T)

SERIAL: 50196

1шт.

3

2120-2130

BOLT M39X3.0X260

desc: BOULON A 6 PANS

4шт.

4

2114-1835

SPACER

desc: BAGUE

4шт.

5

S0775661

BOLT M24X2.0X115

desc: BOULON A 6 PANS

35шт.

6

2123-1107D4

PIN;KNOCK

desc: GOUPILLE

2шт.

7

2160-9010

COVER;RUBBER

desc: COUVERCLE CAOUTCHOUC

1шт.

8

2195-2786A

BRACKET

desc: TAQUET D'ARRET

1шт.

9

S0515253

BOLT M12X1.75X30

desc: BOULON A 6 PANS

3шт.

10

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

11

2403-1002

COVER

desc: COUVERCLE

1шт.

12

2180-1017A

PACKING

desc: RONDELLE ETANCHE

1шт.

13

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

2шт.

14

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

15

2160-1201D11

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

1шт.

17

2160-1004D31

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

1шт.

18

2160-1004D42

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

1шт.

20

2160-1201D12

BUSHING;RUBBER

desc: MANCHON

1шт.

21

S0521961

BOLT M16X2.0X65

desc: BOULON A 6 PANS

2шт.

22

S4012933

NUT M16X2.0

desc: ECROU

2шт.

23

2160-9034

CAP

desc: CHAPEAU

2шт.

24

2627-1203

COVER;LAMP

desc: COUVERCLE

1шт.

25

S0504553

BOLT M6X1.0X14

desc: BOULON A 6 PANS

4шт.

26

S5010313

WASHER;PLAIN

desc: RONDELLE

4шт.
