Запчасти Doosan Daewoo MAIN PIPING-BREAKER OPTION PARTS

-

400-00978

MAIN PIPING

SC: D

-2шт.

1

140-01224A

PIPE

desc: TUYAU

1шт.

2

423-00171

BLOCK;SPACER

desc: BLOC

1шт.

3

DS2016018

HOSE

desc: TUYAU FLEXIBLE

2шт.

4

DS2025040

HOSE 610L

desc: TUYAU FLEXIBLE

1шт.

5

DS2045301

HOSE

desc: TUYAU FLEXIBLE

1шт.

6

DS2040066

HOSE

desc: TUYAU FLEXIBLE

1шт.

7

DS2018069

HOSE

desc: TUYAU FLEXIBLE

1шт.

8

421-00019

VALVE;SWITCH

desc: VANNE

1шт.

9

423-00150

BLOCK

desc: BLOC

1шт.

10

195-01938A

BRACKET

desc: SUPPORT

2шт.

11

195-02016

BRACKET

desc: SUPPORT

1шт.

12

S8030161

O-RING

desc: JONT TORIQUE

4шт.

13

S8000291

O-RING

desc: JONT TORIQUE

1шт.

14

2181-4133D6

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

15

2124-1026D3

CLAMP;PIPE

desc: ATTACHE DE TUBE

1шт.

16

S2214066

BOLT;SOCKET M10X1.5X120

desc: BOULON DE PLOT

4шт.

17

2181-9078

FLANGE;SPLIT

desc: BRIDE

16шт.

18

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON DE PLOT

28шт.

19

S2212466

BOLT;SOCKET M10X1.5X40

desc: BOULON DE PLOT

4шт.

20

S0512253

BOLT M10X1.5X30

desc: BOULON A 6PANS

4шт.

21

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

22

S0561053

BOLT M12X1.75X65

desc: BOULON A 6PANS

1шт.

23

S2215866

BOLT;SOCKET M12X1.75X60

desc: BOULON DE PLOT

2шт.

24

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

5шт.

25

2180-1026D19

O-RING

desc: JONT TORIQUE

10шт.

26

S0515253

BOLT M12X1.75X30

desc: BOULON A 6PANS

4шт.
