CYLINDER HEAD

Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

218
210
228
211
230
212
229
220
228
219
231
202
223
206
224
207
204
208
205
203
201
117
112
102
113
111
108
118
123
128
119
129
105
124
106
130
131
120
121
132
122
101
104
116
109
109
107
125
133
134
110
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

101

65.03101-6071B

CYLINDER HEAD ASS'Y

desc: ENSEMBLE CULASSE

1шт.

102

65.03101-1043C

HEAD;CYLINDER

SC: D

1шт.

104

65.03201-1013A

GUIDE;VALVE

SC: B

12шт.

105

65.03203-1054

SEAT;EXHAUST VALVE

SC: B

6шт.

106

65.03203-1053

SEAT;INLET VALVE

SC: B

6шт.

107

65.90302-0015

PLUG;CORE(NEAR FACE)

desc: . BOUCHON

1шт.

108

65.90302-0030

PLUG;CORE(EXHAUST MAIN)

desc: . BOUCHON

6шт.

109

65.90302-0019B

PLUG;CORE

desc: . COUPELLE

11шт.

110

65.90302-0045

PLUG;CORE

desc: . BOUCHON

3шт.

111

65.90302-0027

PLUG;CORE

desc: . BOUCHON

6шт.

112

65.90302-0011

PLUG;DRILLED PASS

desc: . BOUCHON

6шт.

113

65.90302-0017

PLUG;WATER JET CORE

desc: BOUCHON

6шт.

116

06.06225-0706

BOLT;STUD M8X25

desc: BOULON DE GOUJON

3шт.

117

06.06125-8717

BOLT;STUD M8X75

desc: BOULON DE GOUJON

9шт.

118

06.06125-8709

BOLT;STUD M8X35

desc: BOULON DE GOUJON

1шт.

119

65.91710-0004

RING;STOPPER

desc: BAGUE

2шт.

120

65.90021-0002

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

18шт.

121

65.90021-0003

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

6шт.

122

65.90021-0004

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

2шт.

123

06.06125-8723

BOLT;STUD M8X110

desc: BOULON DE GOUJON

2шт.

124

65.19202-5005

HOOK;LIFTING

desc: CROCHET

1шт.

125

65.03901-0066A

GASKET;CYLINDER HEAD

desc: JOINT

1шт.

128

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

129

06.01733-4409

BOLT;HEX M14X1.5X25

desc: BOULON A 6 PANS

1шт.

130

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

131

06.01733-4208

BOLT M10X1.25X22

desc: BOULON A 6 PANS

1шт.

132

65.26815-0002

PLUG;DUMMY

desc: PRISE DE LUEUR

6шт.

133

65.19202-0005

HOOK;LIFTING

desc: CROCHET

1шт.

134

06.01943-3213

BOLT ASS'Y M10X1.25X20

desc: BOULON A 6 PANS

2шт.

201

65.03401-6064A

CYLINDER HEAD COVER ASS'Y

desc: COUVRE-CULASSE

1шт.

202

65.03401-0061A

COVER. CYL.HEAD

desc: . COUVERCLE

1шт.

203

65.03905-0002B

GASKET;CYLINDER HEAD COVER

desc: . RONDELLE D'ETANCHEITE

1шт.

205

65.03903-0001

PACKING;COVER

desc: . EMBALLAGE

1шт.

204

65.01801-0011

CASE;BREATHER

desc: . BOITE

1шт.

206

06.04190-8808

BOLT M5X16

desc: . BOULON A 6 PANS

6шт.

207

06.16731-2104

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

6шт.

208

06.15010-0308

WASHER;PLAIN

desc: . RONDELLE

6шт.

210

65.90501-0028

NUT;CYLINDER HEAD COVER

desc: ECROU

4шт.

211

65.90701-0202

WASHER;PLATE

desc: RONDELLE

4шт.

212

65.03905-0023

GASKET;CYL. HEAD COVER

desc: RONDELLE

4шт.

218

65.96301-0354

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

219

06.67020-0105

CLAMP

desc: ATTACHE DE TUYAU

1шт.

220

65.01810-5007

CAP;OIL FILLER

desc: VIBREUR

1шт.

223

65.01801-5035A

BREATHER PIPE ASS'Y

desc: CLAPET DE RECHANGE

1шт.

224

65.96501-0032B

O-RING

desc: JOINT TORIQUE

1шт.

228

65.97401-0179

CLIP;WATER HOSE

desc: CLIP

2шт.

229

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

230

06.11063-8214

NUT;HEX M8

desc: ECROU

1шт.

231

06.01913-3111

BOLT ASS'Y M8X16

desc: BOULON A 6 PANS

1шт.
