Запчасти Doosan Daewoo AIRCONDITIONER(1) BODY PARTS

-

920-00083

COOLER & HEATER PIPING

SC: D

-2шт.

1

543-00049

PANEL;AIRCON CONTROL

desc: PANNEAU

1шт.

2

S3450583

SCREW

desc: VIS

4шт.

3

S5000113

WASHER;PLAIN M4

desc: RONDELLE PLATE

4шт.

4

2208-6013B

COMPRESSOR

desc: COMPRESSEUR

1шт.

5

S0557153

BOLT M8X1.25X90

desc: BOULON A 6PANS

4шт.

6

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

7

S5010513

WASHER;PLAIN M8

desc: RONDELLE

4шт.

8

2197-1798B

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

9

S0712153

BOLT M10X1.25X28

desc: BOULON A 6PANS

1шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

11

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

12

2107-6006

PULLEY ASS'Y;IDLE 4PK

desc: ENSEMBLE POULIE FOU

1шт.

13

S0759853

BOLT M10X1.25X115

desc: BOULON A 6PANS

2шт.

14

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

15

2106-1019D10

V-BELT 4PK L990

desc: COURROIE-V

1шт.

16

185-00344A

HOSE;DISCHARGE L2500

desc: TUYAU FLEXIBLE

1шт.

16A

2180-6089

O-RING(COND)

desc: . JONT TORIQUE

1шт.

16B

2180-6088

O-RING(COMP)

desc: . JONT TORIQUE

1шт.

16C

1.161-00018

CAP;CHECK PORT(H)

desc: . CHAPEAU

1шт.

17

2185-1703B

HOSE;SUCTION L2790

desc: TUYAU FLEXIBLE

1шт.

17A

2180-6086

O-RING(COMP)

desc: . JONT TORIQUE

1шт.

17B

2180-6087

O-RING(EVA)

desc: . JONT TORIQUE

1шт.

17C

1.161-00019

CAP;CHECK PORT(L)

desc: . CHAPEAU

1шт.

18

2520-6007C

CONDENSER ASS'Y

desc: CONDENSATEUR

1шт.

19

S0555953

BOLT M8X1.25X30

desc: BOULON A 6PANS

6шт.

20

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

21

S5010513

WASHER;PLAIN M8

desc: RONDELLE

6шт.

22

195-01904

BRACKET;CONDENSER(L.H)

desc: SUPPORT

1шт.

23

195-01905

BRACKET;CONDENSER(R.H)

desc: SUPPORT

1шт.

24

S0508853

BOLT M8X1.25X20

desc: BOULON A 6PANS

4шт.

25

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

26

2185-1736D2

HOSE;LIQUID(1) L530

desc: TUYAU FLEXIBLE

1шт.

26A

2180-6090

O-RING d6.07/t1.78

desc: . JONT TORIQUE

2шт.

27

2185-1698D4

HOSE;LIQUID(2) L2650

desc: TUYAU FLEXIBLE

1шт.

27A

2180-6090

O-RING d6.07/t1.78

desc: . JONT TORIQUE

2шт.

28

2204-6039A

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

29

S0508653

BOLT M8X1.25X16

desc: BOULON A 6PANS

2шт.

30

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

31

920-00020B

UNIT;AIRCON

desc: UNITE D'AIRCON

1шт.

32

S0509053

BOLT M8X1.25X25

desc: BOULON A 6PANS

6шт.

33

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

34

2114-1058D29

WASHER D26/D9

desc: RONDELLE

6шт.

42

124-00208D7

CLIP D44/M8

desc: CLIP

3шт.

44

120-00276

BOLT M8X1.25

desc: BOULON

3шт.

45

2124-1622D3

CLIP;BAND L280

desc: CLIP

10шт.

46

S4012333

NUT M6X1.0

desc: ECROU

1шт.

47

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

1шт.

48

S5010313

WASHER;PLAIN M6

desc: RONDELLE

1шт.
