Запчасти Doosan Daewoo INTAKE & EXHAUST MANIFOLD ENGINE PARTS

101

65.08101-0199

MANIFOLD;EXHAUST

SERIAL: 061011

1шт.

101

65.08101-0274

MANIFOLD;EXHAUST

SERIAL: 061012

1шт.

103

06.06175-8208

BOLT;STUD M10X1.25X30

desc: GOUJON

4шт.

104

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

12шт.

105

06.15010-2311

WASHER

desc: RONDELLE

12шт.

106

06.11063-8214

NUT

desc: ECROU 6 PANS

12шт.

107

65.08901-0028

GASKET;MANIFOLD EXHAUST

desc: JOINT

3шт.

201

65.08201-5056

MANIFOLD;INTAKE

SERIAL: 060421

1шт.

201

65.08201-5056A

MANIFOLD;INTAKE

SERIAL: 060422

1шт.

212

06.01923-3115

BOLT ASS'Y

SERIAL: 030125

8шт.

212

06.01923-3115

BOLT ASS'Y

SERIAL: 030126

7шт.

214

06.11063-8214

NUT

desc: ECROU

3шт.

215

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

216

06.15010-2311

WASHER

desc: RONDELLE

3шт.

219

65.08902A0004

GASKET;INTAKE MANIFOLD

desc: JOINT

1шт.

220

65.08120-0026

HEAT;SCREEN

desc: LA CHALEUR D'ECRAN

1шт.

221

06.01913-3111

BOLT ASS'Y M8X16

desc: BOULON A 6 PANS

3шт.

230

65.08202-0137

PIPE;INLET

desc: CONDUITES

1шт.

231

65.96301-0279

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

232

06.67020-0109

CLAMP;HOSE

desc: COLLIER

2шт.

233

06.01913-3115

BOLT ASS'Y

desc: BOULON A 6 PANS

4шт.

235

65.09904-0008

GASKET

desc: JOINT

1шт.

401

65.09501-7002

INTER COOLER ASS'Y

desc: REFREGERATOR

1шт.

402

06.01923-3122

BOLT ASS'Y M8X55

desc: BOULON A 6 PANS

17шт.

403

06.01923-3123

BOLT ASS'Y M8X60

desc: BOULON A 6 PANS

1шт.

404

65.26803-7032

AIR HEATER

SERIAL: 040128

1шт.

404

65.26803-7032A

AIR HEATER

SERIAL: 041213

1шт.

404

65.26803-7032B

AIR HEATER

SERIAL: 041214

1шт.

405

65.09905-0003

GASKET;INTER COOLER

SERIAL: 030209

2шт.

405

65.09905-0006

GASKET;INTER COOLER

SERIAL: 030210

2шт.

500

65.91701-0029

SPACER

SERIAL: 030126

1шт.

501

06.01013-9127

BOLT ASS'Y

SERIAL: 030126

1шт.
