Запчасти Doosan Daewoo MAIN PIPING(2) BODY PARTS

-

400-01183

MAIN PIPING

SC: D

-2шт.

2

140-01362

PIPE

desc: TUYAU

1шт.

3

140-01363

PIPE

desc: TUYAU

1шт.

18

2195-3657

BRACKET

desc: SUPPORT

2шт.

19

S0515353

BOLT M12X1.75X35

desc: BOULON A 6 PANS

6шт.

20

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

24

S0561053

BOLT M12X1.75X65

desc: BOULON A 6 PANS

2шт.

25

2124-1025D5

CLAMP

desc: COLLIER

2шт.

28

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS

20шт.

29

2180-1026D19

O-RING

desc: JOINT TORIQUE

2шт.

31

S2212066

BOLT;SOCKET M10X1.5X25

desc: BOULON A 6 PANS

16шт.

32

S2212366

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS

4шт.

33

2180-1026D2

O-RING

desc: JOINT TORIQUE

8шт.

34

2181-9079

FLANGE;SPLIT

desc: BRIDE

16шт.

39

2181-9083

FLANGE;SPLIT

desc: BRIDE

2шт.

45

S5010713

WASHER;PLAIN M12

desc: RONDELLE PLATE

4шт.

46

2184-1081D116

HOSE PF3/4-715L

desc: TUYAU FLEXIBLE

2шт.

47

2184-1081D117

HOSE PF3/4-740L

desc: TUYAU FLEXIBLE

2шт.
