Запчасти Doosan Daewoo TRAVEL PIPING TRACK PARTS

-

2400-2012

TRAVEL PIPING

SC: D

-2шт.

1

2184-1098D69

HOSE PF1-2400L

desc: TUYAU FLEXIBLE

4шт.

3

2181-9078

FLANGE;SPLIT 1"-5000psi

desc: FLASQUE EN DEUX PARTIES

8шт.

4

2181-9081

FLANGE;SPLIT 1"-6000psi

desc: BRIDE

8шт.

5

S2215366

BOLT;SOCKET M12X1.75X35

desc: BOULON A 6 PANS CREUX

16шт.

6

2180-1026D19

O-RING SAE1

desc: JOINT TORIQUE

8шт.

7

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

16шт.

8

S8000181

O-RING 1BP-8

desc: JOINT TORIQUE

3шт.

9

2181-2281D10

TEE 3-PF1/2

desc: TE

1шт.

10

DS2054280

HOSE PF1/4-2700L

desc: TUYAU FLEXIBLE

2шт.

11

2184-1070D48

HOSE PF1/2-2300L

desc: TUYAU FLEXIBLE

2шт.

12

2181-1126D6

ADAPTER PF1/2-PF1/2

desc: RACCORD ADAPTATEUR

2шт.

13

2181-1126D14

ADAPTER PF(O)1/4XPF1/4

desc: RACCORD ADAPTATEUR

3шт.

14

S8000111

O-RING 1BP-11

desc: JOINT TORIQUE

3шт.

15

2181-4125

TEE 1/4

desc: TE

1шт.

16

2160-1322D1

BUSHING;RUBBER

desc: GARNISSAGE CAOUTCHOUC

2шт.

17

2160-1201D11

BUSHING;RUBBER

desc: GARNISSAGE CAOUTCHOUC

2шт.
