Запчасти Doosan Daewoo PILOT PIPING(2) BODY PARTS

-

400-01448

PILOT PIPING

SC: D

-2шт.

3

2891-1244A

PLATE

desc: PLAQUE

1шт.

5

2460-9060

ACCUMULATOR

desc: RESERVOIR

1шт.

6

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

4шт.

7

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

10

2426-9039B

VALVE;PILOT

SERIAL: 1001-1002

1шт.

10

2426-9039C

VALVE;PILOT

SERIAL: 1003

1шт.

24

S8000181

O-RING P18

desc: JOINT TORIQUE

3шт.

25

S8000141

O-RING P14

desc: JOINT TORIQUE

4шт.

26

S8000111

O-RING P11

SERIAL: 1001-1022

3шт.

26

S8000111

O-RING P11

SERIAL: 1023

4шт.

28

2181-1126D7

ADAPTER

SERIAL: 1008

4шт.

29

2181-1126D6

ADAPTER PF(O)1/2XPF1/2

desc: RACCORD ADAPTATEUR

1шт.

30

2181-1126D36

ADAPTER PF(O)3/8XPF1/4

SERIAL: 1001-1007

4шт.

32

2181-1702D4

ELBOW PF(O)1/4XPF1/4

desc: COUDE

2шт.

35

2181-1702D2

ELBOW PF(O)1/2XPF1/2

desc: COUDE

1шт.

38

2181-1951D1

TEE PF(O)1/4X2-PF1/4

desc: TE

1шт.

60

2184-1045D48

HOSE PF1/4-935L

desc: TUYAU FLEXIBLE

1шт.

61

2184-1045D158

HOSE PF1/4-650L

desc: TUYAU FLEXIBLE

1шт.

64

2184-1036D160

HOSE PF1/2-1050L

desc: TUYAU FLEXIBLE

1шт.

81

471-00118

FILTER;REDUCER

SERIAL: 1023

1шт.
