Запчасти Doosan Daewoo MAIN PIPING-ONE & TWO WAY(ARTI.BOOM) OPTION PARTS

-

400-01341

MAIN PIPING

SC: D

-2шт.

1

140-01224

PIPE

desc: TUYAU

1шт.

2

423-00171

BLOCK;SPACER

desc: BLOC

1шт.

3

423-00190

BLOCK

desc: BLOC

2шт.

4

DS2040354

HOSE

desc: TUYAU FLEXIBLE

1шт.

5

DS2045301

HOSE

desc: TUYAU FLEXIBLE

1шт.

6

DS2040066

HOSE

desc: TUYAU FLEXIBLE

1шт.

7

2184-1036D112

HOSE

desc: TUYAU FLEXIBLE

1шт.

8

421-00019

VALVE;SWITCH

desc: VANNE

1шт.

9

423-00150

BLOCK

desc: BLOC

1шт.

10

195-01938A

BRACKET

desc: SUPPORT

2шт.

11

195-02016

BRACKET

desc: SUPPORT

1шт.

13

S8000291

O-RING

desc: JONT TORIQUE

1шт.

14

DS2371036

TEE

desc: TE

1шт.

15

2124-1026D3

CLAMP;PIPE

desc: ATTACHE DE TUBE

1шт.

16

S2214166

BOLT;SOCKET M10X1.5X125

desc: BOULON DE PLOT

4шт.

17

2181-9078

FLANGE;SPLIT

desc: BRIDE

18шт.

18

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON DE PLOT

32шт.

19

S2212466

BOLT;SOCKET M10X1.5X40

desc: BOULON DE PLOT

4шт.

20

S0512253

BOLT M10X1.5X30

desc: BOULON A 6PANS

4шт.

21

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

22

S0561053

BOLT M12X1.75X65

desc: BOULON A 6PANS

1шт.

23

S2215866

BOLT;SOCKET M12X1.75X60

desc: BOULON DE PLOT

2шт.

24

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

5шт.

25

2180-1026D19

O-RING

desc: JONT TORIQUE

11шт.

26

S0515253

BOLT M12X1.75X30

desc: BOULON A 6PANS

4шт.

27

DS2047011

HOSE

desc: TUYAU FLEXIBLE

1шт.

28

S2213166

BOLT;SOCKET M10X1.5X75

desc: BOULON DE PLOT

8шт.
