Запчасти Doosan Daewoo CLAMSHELL PIPING OPTION PARTS

-

H220-9063

CLAMSHELL PIPING

SC: D

-2шт.

1

A004-0020A

PIPE

desc: TUYAU

2шт.

2

H001-0003D16

HOSE 1750L

desc: TUYAU FLEXIBLE

2шт.

3

H001-0004D49

HOSE 800L

desc: TUYAU FLEXIBLE

2шт.

4

2180-1026D2

O-RING

desc: JOINT TORIQUE

4шт.

5

S8000291

O-RING

desc: JOINT TORIQUE

10шт.

6

S8030161

O-RING

desc: JOINT TORIQUE

6шт.

7

S8030121

O-RING

desc: JOINT TORIQUE

4шт.

8

2124-1696

CLAMP;PIPE

desc: FIXATION DE TUYAU

4шт.

9

S0515366

BOLT;HEX M12X1.75X35

desc: BOULON A 6 PANS

4шт.

10

S0560966

BOLT;HEX M12X1.75X60

desc: BOULON A 6 PANS

8шт.

11

S0561366

BOLT;HEX M12X1.75X80

desc: BOULON A 6 PANS

4шт.

12

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

16шт.

13

S5010703

WASHER;PLAN M12

desc: RONDELLE PLATE

4шт.

14

S2215666

BOLT;SOCKET M12X1.75X50

desc: BOULON DE PLOT

4шт.

15

2420-9628A

VALVE;STOP

desc: VANNE

2шт.

16

124-00178

CLAMP;STOP V/V

desc: ATTACHE

2шт.

17

2181-2566D8

ADAPTER;UNION

desc: ADAPTEUR

4шт.

18

2181-2816D2

ELBOW

desc: COUDE

2шт.

19

2181-2817D2

CAP

desc: CHAPEAU

2шт.

20

2181-2627D15

ADAPTER

desc: ADAPTEUR

4шт.

21

2161-2251A

RUBBER

desc: CAOUTCHOUC

8шт.

22

A042-0043A

BRACKET

desc: SUPPORT

2шт.

23

A006-0006A

VALVE;SWITCH

desc: VANNE

2шт.

24

2181-9079

FLANGE;SPLIT

desc: BRIDE

8шт.

25

S2212366

BOLT;SOCKET M10X1.0X35

desc: BOULON DE PLOT

16шт.

26

H220-9064

ARM;SEAT WELDMENT

desc: BALANCHER

1шт.
