Запчасти Doosan Daewoo ENGINE MOUNTING BODY PARTS

-

201-00111B

ENGINE ASS'Y

SC: D

-2шт.

1

201-00012

ENGINE(DB58TIS)

desc: MOTEUR

1шт.

6

2114-9012A

WASHER;HARD

desc: RONDELLE

8шт.

7

S0771466

BOLT M20X1.5X130

desc: BOULON A 6PANS

4шт.

12

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

16

195-01925

BRACKET;ENGINE MOUNTING

desc: SUPPORT; AMORTISSEUR VIB.

1шт.

17

195-01924

BRACKET;ENGINE MOUNTING

desc: SUPPORT; AMORTISSEUR VIB.

1шт.

22

S0786253

BOLT M12X1.5X30

desc: BOULON A 6PANS

8шт.

23

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

8шт.

27

S0515353

BOLT M12X1.75X35

desc: BOULON A 6PANS

2шт.

29

S5010713

WASHER;PALIN

desc: RONDELLE ELASTIQUE

2шт.

31

2161-9066

RUBBER;E/G MOUNTING

desc: CAOUTCHOUC

4шт.

32

4161-9067

RUBBER;E/G MOUNTING

desc: CAOUTCHOUC

4шт.

33

S0712253

BOLT M10X1.25X30

desc: BOULON A 6PANS

7шт.

34

2114-1929

WASHER;BUMP

desc: RONDELLE PLATE

4шт.

35

S4032633

NUT M10X1.25

desc: ECROU

1шт.

36

121-00066

NUT;LOCK M20X1.5

desc: ECROU

4шт.

37

195-01926

BRACKET;ENGINE MOUNTING

desc: SUPPORT; AMORTISSEUR VIB.

1шт.

38

195-01927

BRACKET;ENGINE MOUNTING

desc: SUPPORT; AMORTISSEUR VIB.

1шт.

43

195-02465

BRACKET

desc: SUPPORT

1шт.

44

2120-2196D9

BOLT;SET

desc: BOULON A 6PANS

2шт.
